System And Components
306-8593 BATTERY & WIRING GPS/N CYZ1-225
Group No: 306-8593
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G8767 | 1 WASHER (10.5X60X3-MM THK) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 31 | |
| 3T5760 | 3 BATTERY GP (12-VOLT, 750-CCA) | 2 | |
| 1231373 | CAP AS-FILLER (7/8-9-THD) | 6 | |
| 5I8270 | 4 COVER-BATTERY | 1 | |
| 6G2256 | 5 CLAMP | 2 | |
| 6G2263 | 6 SPACER (10.5X19X28.5-MM THK) | 5 | |
| 6W6005 | 7 HOLD-DOWN-BATTERY | 1 | |
| 7I2673 | 8 STRAP-CABLE | 4 | |
| 7K1181 | 9 STRAP-CABLE | 25 | |
| 7Y1924 | 10 SPACER (9X19X23-MM THK) | 2 | |
| 0857329 | 11 SPACER (9X19X30-MM THK) | 2 | |
| 0919035 | 12 SPACER (11X25X20-MM THK) | 1 | |
| 1114836 | 13 CLIP | 12 | |
| 1114837 | 14 CLIP | 9 | |
| 1114838 | 15 CLIP | 16 | |
| 1114839 | 16 STRAP | 16 | |
| 1160118 | 17 CLIP | 11 | |
| 1321805 | 18 STRAP AS-GROUND | 1 | |
| 1321806 | 19 STRAP AS-GROUND | 1 | |
| 1392118 | 20 SWITCH AS-TOGGLE (SECONDARY SHUTDOWN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1706929 | 21 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(31-CM) | ||
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9W3417 | TERMINAL AS | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9W3722 | TERMINAL AS | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE)(LH) | 1 | |
| 1709336 | 22 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 1831049 | 23 BRACKET | 1 | |
| 2311827 | 24 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0747 | CABLE (00-GA, BLACK) | 23 | |
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 9W3723 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 2314502 | 25 GUARD | 1 | |
| 2382501 | 26 KNOB | 1 | |
| 2382528 | 27 ROD | 1 | |
| 2510467 | 28 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2595267 | 29 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2595317 | 30 BRACKET AS | 1 | |
| 2917466 | 31 BRACKET AS | 1 | |
| 1211029 | CLIP | 1 | |
| 2917591 | 32 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(324-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9G0004 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9W3416 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE)(RH) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 2917593 | 33 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2992767 | 34 WIRE AS | 1 | |
| 3068401 | 35 GROMMET (85-MM ID) | 1 | |
| 3068694 | 36 HARNESS AS-CHASSIS | 1 | |
| 1240986 | 37 GROMMET | 2 | |
| 1325789 | 38 CLIP (LADDER) | 2 | |
| 1566175 | 39 CLIP (LADDER) | 1 | |
| 4K8864 | 40 CLIP (LOOP) | 1 | |
| 4P7428 | 41 CLIP (LADDER) | 1 | |
| 4P7581 | 42 CLIP (LADDER) | 2 | |
| 5C7261 | 43 NUT (M8X1.25-THD) | 1 | |
| 5C7883 | 44 BOLT-SOCKET HEAD (M6X1X16-MM) | 4 | |
| 5I3878 | 45 GROMMET (50-MM ID) | 1 | |
| 5P4116 | 46 WASHER-HARD (8.8X20.5X2-MM THK) | 5 | |
| 6K8178 | 47 CLIP (LOOP) | 4 | |
| 7X0818 | 48 BOLT (M8X1.25X45-MM) | 2 | |
| 7X2621 | 49 BOLT (M10X1.5X12-MM) | 2 | |
| 7Y8165 | 50 GROMMET | 1 | |
| 7Y8167 | 51 GROMMET (50-MM ID) | 1 | |
| 8M2770 | 52 CLIP (LOOP) | 1 | |
| 8T0286 | 53 BOLT (M5X0.8X8-MM) | 1 | |
| 8T0328 | 54 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 63 | |
| 8T4133 | 56 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 57 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4137 | 58 BOLT (M10X1.5X20-MM) | 39 | |
| 8T4171 | 59 BOLT (M6X1X12-MM) (M6X1X12-MM) | 1 | |
| 8T4182 | 60 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4185 | 61 BOLT (M10X1.5X50-MM) | 3 | |
| 8T4191 | 62 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4195 | 63 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 64 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4199 | 65 BOLT (M8X1.25X12-MM) | 1 | |
| 8T4226 | 66 WASHER-PLATED (10.5X45X3-MM THK) | 1 | |
| 8T6466 | 67 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6912 | 68 BOLT (M8X1.25X50-MM) | 2 | |
| 9X8256 | 69 WASHER (6.6X12X2-MM THK) | 5 |
