System And Components
283-2978 LIGHTING GP-FLOOD -BOOMS/N CYZ1-394
Group No: 283-2978
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114836 | 1 CLIP | 6 | |
| 1160118 | 2 CLIP | 1 | |
| 2832975 | 3 BRACKET AS | 2 | |
| 2833012 | 4 HARNESS AS-LIGHTING | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 2838144 | 5 LAMP GP-FLOOD (24-VOLT, 35-WATT) | 2 | |
| 1114837 | 6 CLIP | 1 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 8 NUT (M10X1.5-THD) | 7 | |
| 8T4190 | 9 BOLT (M16X2X25-MM) | 4 | |
| 9X8257 | 10 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 7I2673 | 11 STRAP-CABLE | 2 | |
| 5P9297 | 12 CLIP (LOOP) | 2 | |
| 3S2093 | 13 STRAP-CABLE | 1 |
