324-5708 PANEL GP-CIRCUIT BREAKERS/N CYZ1-225

Group No: 324-5708

Part Number	Part Name	Qty
3E8320	1 PLATE-INSTRUCTION (BATTERY)	1
7N0719	2 SWITCH GP-DISCONNECT (BATTERY)	1
1160114	3 SWITCH AS-MAGNETIC (24-VOLT)(HEATER RELAY)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	2
1028802	KIT-RECEPTACLE (2-PIN)	1
1211023	4 BLOCK-TERMINAL	1
1712210	5 CIRCUIT BREAKER AS (80-AMPERE)	2
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
2532111	LOCKWASHER	2
1974330	6 CONTROLLER-AIR (HEATER)	1
2164970	7 CIRCUIT BREAKER AS (120-AMPERE)	1
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
2532111	LOCKWASHER	2
2341037	8 WIRE AS	1
2341038	9 WIRE AS	1
2382279	10 BAR-BUS	1
2382324	11 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)	1
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
2382325	12 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)	1
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
2510303	13 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)	1
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
2510304	14 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)	1
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
2595274	15 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)	1
2917547	16 BRACKET AS	1
3068689	17 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)	1
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
3191344	18 BRACKET AS	1
3191346	19 COVER AS	1
5C2890	20 NUT (M6X1-THD)	2
5C9553	21 BOLT (M6X1X16-MM)	5
5P4115	22 WASHER-HARD (7.2X19X2-MM THK)	4
6V5645	23 SCREW-MACHINE (10-32X0.87-IN)	6
7X2619	24 BOLT (M6X1X10-MM)	2
8T0328	25 WASHER-HARD (5.5X10X1-MM THK)	6
8T4171	26 BOLT (M6X1X12-MM) (M6X1X12-MM)	4
8T4970	27 BOLT (M6X1X14-MM)	6
9X8256	28 WASHER (6.6X12X2-MM THK)	15
