System And Components
328-0161 PANEL GP-CIRCUIT BREAKERS/N CYZ226-UP
Group No: 328-0161
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 7N0719 | 3 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 1211023 | 4 BLOCK-TERMINAL | 1 | |
| 1412759 | 5 FUSE (5-AMPERE) | 1 | |
| 1712210 | 6 CIRCUIT BREAKER AS (80-AMPERE) | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 2095582 | 7 SWITCH GP-MAGNETIC (24-VOLT) | 1 | |
| 2164970 | 8 CIRCUIT BREAKER AS (120-AMPERE) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 2381506 | 9 COVER | 1 | |
| 2382279 | 10 BAR-BUS | 1 | |
| 2510303 | 11 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.02-M) | ||
| 1311478 | TERMINAL AS | 2 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2510304 | 12 CABLE AS | 1 | |
| 6V2366 | CABLE-ELECTRICAL (4-GA, RED)(0.02-M) | ||
| 1311478 | TERMINAL AS | 2 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2595274 | 13 SWITCH GP-MAGNETIC (24-VOLT) | 1 | |
| 3068689 | 14 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.03-M) | ||
| 1311478 | TERMINAL AS | 2 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 3245802 | 15 BRACKET AS | 1 | |
| 3245804 | 16 WIRE AS | 1 | |
| 3245805 | 17 WIRE AS | 1 | |
| 3245806 | 18 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.02-M) | ||
| 1311478 | TERMINAL AS | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 1311479 | TERMINAL AS | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 3245807 | 19 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.03-M) | ||
| 1311478 | TERMINAL AS | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 1311479 | TERMINAL AS | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 3245808 | 20 HOLDER AS-FUSE | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1069615 | PIN-CONNECTOR | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1311505 | TERMINAL AS | 1 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM) | ||
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 1566175 | 21 CLIP (LADDER) | 1 | |
| 5C9553 | 22 BOLT (M6X1X16-MM) | 5 | |
| 5P4115 | 23 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 6V5645 | 24 SCREW-MACHINE (10-32X0.87-IN) | 6 | |
| 8T0328 | 25 WASHER-HARD (5.5X10X1-MM THK) | 6 | |
| 8T4171 | 26 BOLT (M6X1X12-MM) (M6X1X12-MM) | 4 | |
| 8T4970 | 27 BOLT (M6X1X14-MM) | 6 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 11 |
