306-8681 WIRING GP-CAB RISER -457-MM (18-IN)S/N CYZ1-235

Group No: 306-8681
Part NumberPart NameQty
7K11811 STRAP-CABLE2
11148382 CLIP6
11148393 STRAP6
15166674 SUPPORT AS1
8T3490NUT-WELD (M10X1.5-THD)1
16735835 STRAP AS-GROUND1
19742736 BRACKET1
32799567 HARNESS AS-CHASSIS1
7Y3952PLUG-CONNECTOR (2-PIN)1
1211022DIODE1
1343296HOUSING-PLUG1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)12
9W0852PIN-CONNECTOR (14-GA TO 16-GA)17
9X3401PIN-CONNECTOR (16-GA TO 18-GA)45
1275483PLUG AS-CONNECTOR (1-PIN)1
1532620PLUG AS-CONNECTOR (54-PIN, BLACK)1
1636759SEAL1
1552270KIT-CONNECTING PLUG (2-PIN)1
2304009PLUG AS-CONNECTOR (12-PIN)1
2647034SEAL-CONNECTOR1
2304011PLUG AS-CONNECTOR (2-PIN)2
2647029SEAL-CONNECTOR1
2305010PLUG AS-CONNECTOR (6-PIN)1
2647032SEAL-CONNECTOR1
8T8737PLUG-SEAL43
9X1343RECEPTACLE AS-CONNECTOR (40-PIN)1
1636637RECEPTACLE AS-CONNECTOR (54-PIN, BLACK)1
2434505RECEPTACLE AS-CONNECTOR (2-PIN)2
2434509RECEPTACLE AS-CONNECTOR (8-PIN)1
1343297SEAL2
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)11
8N1549SOCKET-CONNECTOR (4-GA)1
9W0844SOCKET-CONNECTOR (14-GA TO 16-GA)11
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)45
3S2093STRAP-CABLE3
9X0196TERMINAL AS (16-GA)2
9G4343TERMINAL-RING (4-GA, 1/4-IN SCREW)1
7Y3951TERMINAL-BLADE (14-GA)2
1160255TERMINAL-BLADE (10-GA TO 20-GA)1
1211039TERMINAL (MALE)1
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM)
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM)
09661668 WASHER-HARD (4.5X9X1-MM THK)4
16221659 BOLT-SOCKET HEAD (M4X0.7X16-MM)4
2V321610 CLIP (LOOP)1
4D951711 CLIP1
5C788312 BOLT-SOCKET HEAD (M6X1X16-MM)4
8T412113 WASHER-HARD (11X21X2.5-MM THK)10
8T413614 BOLT (M10X1.5X25-MM)2
8T413715 BOLT (M10X1.5X20-MM)6
8T419116 BOLT (M10X1.5X16-MM)2
9X825617 WASHER (6.6X12X2-MM THK)4
