System And Components
378-8190 WIRING GP-CHASSISS/N CYZ311-UP
Group No: 378-8190
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I7889 | 1 SPACER (11X25X45-MM THK) | 3 | |
| 7K1181 | 2 STRAP-CABLE | 20 | |
| 1114838 | 3 CLIP | 4 | |
| 1114839 | 4 STRAP | 4 | |
| 1160118 | 5 CLIP | 1 | |
| 1495050 | 6 RELAY (24-VOLT) | 4 | |
| 2917494 | 7 COVER AS | 1 | |
| 3788191 | 8 HARNESS AS-CHASSIS | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 7 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 1495051 | CONNECTOR-RECEPTACLE | 4 | |
| 1495069 | TERMINAL-BLADE (14-GA TO 20-GA) | 8 | |
| 1495070 | TERMINAL-BLADE (16-GA TO 20-GA) | 10 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2434507 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 3788192 | 9 HARNESS AS-SOLENOID | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 7X2619 | 10 BOLT (M6X1X10-MM) | 4 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 1 | |
| 8T5005 | 14 BOLT (M10X1.5X70-MM) | 3 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 4 |
