System And Components
306-1401 HOOD & GUARD GPS/N CYZ214-229
Group No: 306-1401
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R9958 | 1 LATCH AS | 1 | |
| 4I0117 | 2 LATCH AS | 1 | |
| 4I0118 | 3 HOOK AS | 2 | |
| 4I0232 | 4 STRIKER | 2 | |
| 4I8019 | 5 SUPPORT | 3 | |
| 6I6033 | 6 STOP | 3 | |
| 7Y2853 | 7 SPACER (13X38X5-MM THK) | 8 | |
| 0873908 | 8 SHIM (1-MM THK) | 4 | |
| 0873909 | 9 SHIM (2-MM THK) | 4 | |
| 1161628 | 10 SUPPORT AS | 1 | |
| 1223979 | 11 BAND | 1 | |
| 1223980 | 12 ROD | 1 | |
| 1224120 | 13 ROD | 3 | |
| 1358573 | 14 BOLT AS | 65 | |
| 1358575 | 15 BOLT AS | 35 | |
| 1358577 | 16 BOLT AS | 4 | |
| 1358578 | 17 BOLT AS | 6 | |
| 1703016 | 18 SPACER (19X32X2-MM THK) | 15 | |
| 1848423 | 19 SUPPORT AS | 1 | |
| 1906880 | 20 SUPPORT AS | 3 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 2034889 | 21 SPRING | 1 | |
| 2034890 | 22 SPRING | 1 | |
| 2085366 | 23 BUSHING | 5 | |
| 3138249 | 24 COVER AS | 1 | |
| 2448207 | 25 COVER AS | 1 | |
| 3301182 | 26 SUPPORT AS | 1 | |
| 2448228 | 27 SUPPORT AS | 1 | |
| 2448242 | 28 SUPPORT AS | 1 | |
| 3284952 | 29 SUPPORT AS | 1 | |
| 2488943 | LINER | 1 | |
| 2488944 | LINER | 1 | |
| 2896464 | 30 HOOD GP-ENGINE | 1 | |
| 2622324 | 31 COVER AS | 1 | |
| 2622353 | 32 COVER AS | 1 | |
| 2622363 | 33 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2622365 | LINER | 1 | |
| 2783836 | 34 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2783842 | 35 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3301184 | 36 SUPPORT AS | 1 | |
| 3301303 | 37 SHEET AS | 1 | |
| 2866220 | 38 SHEET AS | 1 | |
| 2866276 | LINER | 1 | |
| 2896572 | 39 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896695 | 40 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896698 | 41 SUPPORT AS | 1 | |
| 1293400 | GUARD | 1 | |
| 2448198 | LINER | 1 | |
| 2896699 | 42 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896913 | 43 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 2896917 | 44 DOOR GP-ACCESS (RADIATOR) | 1 | |
| 2936982 | 45 SHEET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 2937056 | 46 SHEET AS | 1 | |
| 2982977 | 47 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 2982979 | 48 COVER AS-ACCESS (FUEL, HYDRAULIC TANKS) | 1 | |
| 2983038 | 49 SUPPORT AS | 1 | |
| 2983041 | 50 SUPPORT AS | 1 | |
| 2783832 | LINER | 1 | |
| 2983042 | SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2983044 | 51 COVER AS | 1 | |
| 3061315 | 52 SUPPORT AS | 1 | |
| 3061317 | 53 SUPPORT AS | 1 | |
| 3061331 | 54 HANDRAIL AS | 1 | |
| 3061333 | 55 HANDRAIL AS | 1 | |
| 3061391 | 56 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 5 | |
| 3061328 | 57 HANDRAIL AS | 1 | |
| 3061493 | 58 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 8 | |
| 9R2060 | BOSS (M10X1.5X21-MM) | 2 | |
| 3061497 | 59 SUPPORT AS | 1 | |
| 2448277 | LINER | 1 | |
| 2448278 | LINER | 1 | |
| 2448288 | LINER | 1 | |
| 3061498 | SUPPORT AS | 1 | |
| 3077700 | 60 SHEET AS-SOUND SUPPRESSION | 1 | |
| 6P2216 | CAP (PUSH ON) | 3 | |
| 3077702 | INSULATION | 1 | |
| 3B4618 | 61 PIN-COTTER | 4 | |
| 1053487 | 62 BOLT-SOCKET HEAD (M6X1X20-MM) | 6 | |
| 1146285 | 63 BAR | 2 | |
| 5C9553 | 64 BOLT (M6X1X16-MM) | 8 | |
| 5P1076 | 65 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P4115 | 66 WASHER-HARD (7.2X19X2-MM THK) | 16 | |
| 7Y2854 | 67 SPACER (24X38X3-MM THK) | 8 | |
| 8T4121 | 68 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 69 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4138 | 70 BOLT (M6X1X20-MM) | 10 | |
| 8T4189 | 71 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 72 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 73 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4648 | 74 BOLT (M12X1.75X70-MM) | 2 | |
| 8T4908 | 75 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4910 | 76 BOLT (M12X1.75X60-MM) | 4 | |
| 9X8256 | 77 WASHER (6.6X12X2-MM THK) | 8 | |
| 3364538 | 78 SPACER (13.8X30X30-MM THK) | 1 | |
| 2983282 | SCREEN AS (HOOD, LH) | 1 | |
| 2896567 | BRACKET | 1 | |
| 0964034 | BOLT-WING (M6X1X15-MM) | 1 |
