System And Components
279-2707 LINES GP-STICK -HARVESTER HEADS/N CYZ1-UP
Group No: 279-2707
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7J9108 | 1 SEAL-O-RING | 2 | |
| 7I8323 | 2 HOSE AS | 1 | |
| 7K1181 | 3 STRAP-CABLE | 3 | |
| 1136677 | 4 HOSE AS | 2 | |
| 1491738 | 5 CLIP | 8 | |
| 1737895 | 6 CLIP | 8 | |
| 1864017 | 7 HOSE AS | 2 | |
| 2472904 | 8 TUBE AS | 1 | |
| 2472905 | 9 TUBE AS | 1 | |
| 3030012 | 10 TUBE AS | 1 | |
| 3030013 | 11 TUBE AS | 1 | |
| 2472908 | 12 TUBE AS | 1 | |
| 1488414 | 13 REDUCER AS | 2 | |
| 6V8943 | REDUCER | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1P3704 | 14 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 15 FLANGE-HALF | 8 | |
| 6V8398 | 16 SEAL-O-RING | 2 | |
| 6V9746 | 17 SEAL-O-RING | 2 | |
| 7Y4038 | 18 CLAMP-HALF | 12 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 28 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 44 |
