System And Components
245-7922 CONSOLE GP-OPERATORS/N CYZ1-235
Group No: 245-7922
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1761916 | 1 GROMMET | 2 | |
| 1785422 | 2 GROMMET | 2 | |
| 1785423 | 3 GROMMET | 2 | |
| 1858161 | 4 INSULATOR | 2 | |
| 2358893 | 5 SUPPORT | 2 | |
| 2358894 | 6 SUPPORT | 2 | |
| 2597349 | 7 CONSOLE GP-OPERATOR (LH) | 1 | |
| 2597348 | 8 CONSOLE GP-OPERATOR (RH) | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4195 | 10 BOLT (M10X1.5X30-MM) | 4 | |
| 9X2046 | 11 SCREW-TRUSS HEAD (M6X1X35-MM) | 8 | |
| 9X2045 | 12 SCREW-TRUSS HEAD (M6X1X20-MM) | 12 | |
| 7K1181 | 13 STRAP-CABLE | 4 | |
| 1229617 | 14 GUARD | 2 |
