System And Components
421-1434 CONSOLE GP-OPERATOR -LHS/N CYZ1-UP
Group No: 421-1434
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1282135 | 1 SCREW-TRUSS HEAD (M6X1X13-MM) | 5 | |
| 1717325 | 2 SCREW-TAPPING (M5X0.8-THD) | 3 | |
| 2346579 | 3 NUT-SPEED | 6 | |
| 2346580 | 4 CAP | 4 | |
| 2346603 | 5 COVER | 1 | |
| 2346605 | 6 COVER | 1 | |
| 2346608 | 7 COVER | 1 | |
| 2346609 | 8 COVER | 1 | |
| 2346610 | 9 COVER | 1 | |
| 2346612 | 11 COVER | 1 | |
| 2346613 | 12 LEVER GP-CONTROL (HYDRAULIC LOCKOUT) | 1 | |
| 2346614 | 13 COVER | 1 | |
| 2358914 | 14 NUT-SPEED | 4 | |
| 2358965 | 15 GUARD | 1 | |
| 2457790 | 16 SCREW-TAPPING (10-16X0.625-IN) | 3 | |
| 2457925 | 17 SUPPORT AS | 1 | |
| 2457948 | 18 SCREW-TAPPING (10-16X0.5-IN) | 7 | |
| 2597202 | 19 ASHTRAY | 1 | |
| 2597347 | 20 ARMREST GP (LH) | 1 | |
| 9X2041 | 21 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 3 | |
| 9X2042 | 22 SCREW-TRUSS HEAD (M6X1X12-MM) (M6X1X12-MM) | 2 |
