System And Components
234-6594 WIPER GP-WINDOW -FRONT, UPPERS/N CYZ1-UP
Group No: 234-6594
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1613677 | 1 HOLDER | 1 | |
| 2457931 | 2 MOTOR AS-WINDOW WIPER | 1 | |
| 6V8231 | NUT (M10X1.25-THD) | 1 | |
| 7Y3470 | NUT (M20X1-THD) | 1 | |
| 7Y3472 | CAP | 1 | |
| 1243953 | WASHER (20.5X30X2-MM THK) | 1 | |
| 2358932 | 3 NOZZLE AS | 1 | |
| 1557042 | 4 RELAY AS (WIPER) | 1 | |
| 3729334 | 5 ARM GP-WINDOW WIPER | 1 | |
| 1613669 | GUIDE | 1 | |
| 1613670 | BLADE AS-WIPER (600-MM) | 1 | |
| 1858290 | SCREW AS (M3.5X0.6X9-MM) | 1 | |
| 3729285 | ARM AS-WIPER | 1 | |
| 1636795 | 6 STRAP-CABLE | 1 | |
| 3E9872 | 7 SCREW AS (M4X0.7X12-MM) | 2 | |
| 4I3090 | 8 SEAL | 1 | |
| 7Y7364 | 9 GROMMET | 1 | |
| 5C2890 | 10 NUT (M6X1-THD) | 4 | |
| 9X2042 | 11 SCREW-TRUSS HEAD (M6X1X12-MM) (M6X1X12-MM) | 2 | |
| 9X2044 | 12 SCREW-TRUSS HEAD (M6X1X16-MM) | 3 |
