System And Components
283-2970 PANEL GP-CIRCUIT BREAKERS/N BWW1-102
Group No: 283-2970
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 7K1181 | 2 STRAP-CABLE | 5 | |
| 7N0719 | 3 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 1028016 | 4 RESISTOR AS (BACKUP) | 1 | |
| 1059985 | 5 CLIP | 3 | |
| 1059986 | 6 CLIP | 4 | |
| 1138490 | 7 FUSE (10-AMPERE) | 20 | |
| 1138491 | 8 FUSE (15-AMPERE) | 7 | |
| 1138493 | 9 FUSE (25-AMPERE) | 2 | |
| 1211023 | 10 BLOCK-TERMINAL | 1 | |
| 1243548 | 11 FUSE (30-AMPERE) | 2 | |
| 1251302 | 12 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1364055 | 13 STRIP | 1 | |
| 1412759 | 14 FUSE (5-AMPERE) | 7 | |
| 1495050 | 15 RELAY (24-VOLT)(CAB RISER LIGHTS) | 1 | |
| 1495050 | 15A RELAY (24-VOLT)(WORK LIGHTS, REAR) | 1 | |
| 1613128 | 16 RELAY (24-VOLT)(HORN) | 1 | |
| 1613128 | 16A RELAY (24-VOLT)(NEUTRAL START) | 1 | |
| 1613128 | 16B RELAY (24-VOLT)(TRAVEL ALARM) | 1 | |
| 1613128 | 16C RELAY (24-VOLT)(CAB FLOODLIGHT, SIDE) | 1 | |
| 1613128 | 16D RELAY (24-VOLT)(BOOM FLOODLIGHT) | 1 | |
| 1613128 | 16E RELAY (24-VOLT)(CHASSIS FLOODLIGHT) | 1 | |
| 1613128 | 16F RELAY (24-VOLT)(CAB FLOODLIGHT) | 1 | |
| 1706888 | 17 PULLER-FUSE | 1 | |
| 2130772 | 18 SWITCH AS-MAGNETIC (24-VOLT)(MAIN RELAY) | 1 | |
| 2164970 | 19 CIRCUIT BREAKER AS (120-AMPERE)(HEATER) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 2382279 | 20 BAR-BUS | 1 | |
| 2382526 | 21 COVER | 1 | |
| 2678065 | 22 CABLE AS | 1 | |
| 2678066 | 23 CABLE AS | 1 | |
| 2678067 | 24 CABLE AS | 1 | |
| 2678068 | 25 WIRE AS (8-GA) | 1 | |
| 2678069 | 26 WIRE AS (8-GA) | 1 | |
| 2678070 | 27 CABLE AS | 1 | |
| 2832971 | 28 HARNESS AS-PANEL | 1 | |
| 2832972 | 29 BRACKET AS | 1 | |
| 2832973 | 30 COVER AS-PANEL | 1 | |
| 0950742 | 31 SCREW-MACHINE (M6X1X16-MM) | 4 | |
| 0965962 | 32 WASHER-HARD (3.4X7X0.8-MM THK) | 4 | |
| 0966166 | 33 WASHER-HARD (4.5X9X1-MM THK) | 8 | |
| 1673593 | 34 STRAP | 1 | |
| 1712210 | 35 CIRCUIT BREAKER AS (80-AMPERE)(MAIN) | 1 | |
| 1712210 | 35A CIRCUIT BREAKER AS (80-AMPERE)(ALTERNATOR) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 1807451 | 36 WASHER-HARD (5.3X8.8X2-MM THK) | 3 | |
| 3E8048 | 37 SCREW-MACHINE (M3X0.5X6-MM) | 4 | |
| 6V5645 | 38 SCREW-MACHINE (10-32X0.87-IN) | 6 | |
| 7X2619 | 39 BOLT (M6X1X10-MM) | 7 | |
| 8C7581 | 40 SCREW-MACHINE (M4X0.7X8-MM) | 11 | |
| 8T0328 | 41 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4121 | 42 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4127 | 43 SCREW-MACHINE (M5X0.8X20-MM) | 2 | |
| 8T4133 | 44 NUT (M10X1.5-THD) | 4 | |
| 8T4191 | 45 BOLT (M10X1.5X16-MM) | 2 | |
| 8T6411 | 46 SCREW-MACHINE (M6X1X12-MM) (M6X1X12-MM) | 8 | |
| 9X8256 | 47 WASHER (6.6X12X2-MM THK) | 19 |
