System And Components
319-1411 PANEL GP-CIRCUIT BREAKERS/N BWW103-UP
Group No: 319-1411
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 7K1181 | 2 STRAP-CABLE | 11 | |
| 7N0719 | 3 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 0857329 | 4 SPACER (9X19X30-MM THK) | 2 | |
| 1028016 | 5 RESISTOR AS (BACKUP) | 1 | |
| 1059985 | 6 CLIP | 3 | |
| 1059986 | 7 CLIP | 4 | |
| 1138490 | 8 FUSE (10-AMPERE) | 20 | |
| 1138491 | 9 FUSE (15-AMPERE) | 7 | |
| 1138493 | 10 FUSE (25-AMPERE) | 2 | |
| 1160114 | 11 SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1211023 | 12 BLOCK-TERMINAL | 1 | |
| 1243548 | 13 FUSE (30-AMPERE) | 2 | |
| 1364055 | 14 STRIP | 1 | |
| 1412759 | 15 FUSE (5-AMPERE) | 7 | |
| 1495050 | 16 RELAY (24-VOLT) | 2 | |
| 1613128 | 17 RELAY (24-VOLT) | 7 | |
| 1673593 | 18 STRAP | 1 | |
| 1706888 | 19 PULLER-FUSE | 1 | |
| 1712210 | 20 CIRCUIT BREAKER AS (80-AMPERE) | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 1974330 | 21 CONTROLLER-AIR (HEATER) | 1 | |
| 2130772 | 22 SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 2164970 | 23 CIRCUIT BREAKER AS (120-AMPERE) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 2382279 | 24 BAR-BUS | 1 | |
| 2382526 | 25 COVER | 1 | |
| 2595274 | 26 SWITCH GP-MAGNETIC (24-VOLT) | 1 | |
| 2678065 | 27 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2678066 | 28 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2678068 | 29 WIRE AS (8-GA) | 1 | |
| 2678069 | 30 WIRE AS (8-GA) | 1 | |
| 2678070 | 31 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 2832971 | 32 HARNESS AS-PANEL | 1 | |
| 2832972 | 33 BRACKET AS | 1 | |
| 3D9143 | HINGE-BUTT | 2 | |
| 5C8312 | NUT (M4X0.7-THD) | 1 | |
| 1211029 | CLIP | 9 | |
| 2832973 | 34 COVER AS-PANEL | 1 | |
| 5C8312 | NUT (M4X0.7-THD) | 2 | |
| 3191359 | 35 HARNESS AS-PANEL | 1 | |
| 3191360 | 36 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 3191361 | 37 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.6-M) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 3191363 | 38 PLATE AS | 1 | |
| 0950742 | 39 SCREW-MACHINE (M6X1X16-MM) | 4 | |
| 0965962 | 40 WASHER-HARD (3.4X7X0.8-MM THK) | 4 | |
| 0966166 | 41 WASHER-HARD (4.5X9X1-MM THK) | 8 | |
| 1807451 | 42 WASHER-HARD (5.3X8.8X2-MM THK) | 3 | |
| 3E8048 | 43 SCREW-MACHINE (M3X0.5X6-MM) | 4 | |
| 5C2890 | 44 NUT (M6X1-THD) | 2 | |
| 6V5645 | 45 SCREW-MACHINE (10-32X0.87-IN) | 6 | |
| 7X2619 | 46 BOLT (M6X1X10-MM) | 9 | |
| 8C7581 | 47 SCREW-MACHINE (M4X0.7X8-MM) | 11 | |
| 8C8451 | 48 BOLT (M6X1X40-MM) | 2 | |
| 8T0328 | 49 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4121 | 50 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4127 | 51 SCREW-MACHINE (M5X0.8X20-MM) | 2 | |
| 8T4133 | 52 NUT (M10X1.5-THD) | 4 | |
| 8T4171 | 53 BOLT (M6X1X12-MM) (M6X1X12-MM) | 2 | |
| 8T4191 | 54 BOLT (M10X1.5X16-MM) | 2 | |
| 8T6411 | 55 SCREW-MACHINE (M6X1X12-MM) (M6X1X12-MM) | 8 | |
| 9X8256 | 56 WASHER (6.6X12X2-MM THK) | 27 |
