System And Components
286-6285 HOOD & GUARD GPS/N BWW1-106
Group No: 286-6285
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R9958 | 1 LATCH AS | 1 | |
| 4E1384 | 2 BUMPER-CONICAL | 6 | |
| 4I0117 | 3 LATCH AS | 1 | |
| 4I0118 | 4 HOOK AS | 2 | |
| 4I2599 | 5 SOCKET | 3 | |
| 5P0540 | 6 NUT-HEX FULL (9/16-18-THD) | 4 | |
| 2462641 | 7 PADLOCK GP | 2 | |
| 5P8500 | KEY | 1 | |
| 7Y2853 | 8 SPACER (13X38X5-MM THK) | 8 | |
| 8T1578 | 9 PAWL (LATCH) | 2 | |
| 8Y4000 | 10 LATCH AS (T-BAR, COMPARTMENT) | 2 | |
| 9M3835 | 11 LATCH-RUBBER | 1 | |
| 0964034 | 12 BOLT-WING (M6X1X15-MM) | 3 | |
| 0964129 | 13 CUSHION | 2 | |
| 1161628 | 14 SUPPORT AS | 1 | |
| 1224120 | 15 ROD | 3 | |
| 1313954 | 16 BRACKET AS | 3 | |
| 1313957 | 17 BAR | 2 | |
| 1358573 | 18 BOLT AS | 50 | |
| 1358575 | 19 BOLT AS | 32 | |
| 1358577 | 20 BOLT AS | 31 | |
| 1358578 | 21 BOLT AS | 6 | |
| 1703016 | 22 SPACER (19X32X2-MM THK) | 13 | |
| 1848423 | 23 SUPPORT AS | 1 | |
| 7Y2916 | PIN-CLEVIS | 1 | |
| 1848424 | PLATE | 1 | |
| 2034889 | 24 SPRING | 1 | |
| 2034890 | 25 SPRING | 1 | |
| 2265929 | 26 SHIM (3-MM THK) | 1 | |
| 3138249 | 27 COVER AS | 1 | |
| 2448207 | 28 COVER AS | 1 | |
| 2622324 | 29 COVER AS | 1 | |
| 2937056 | 30 SHEET AS | 1 | |
| 2622353 | 31 COVER AS | 1 | |
| 2983276 | 32 SCREEN AS (RADIATOR DOOR, FRONT) | 1 | |
| 2983044 | 33 COVER AS | 1 | |
| 2866220 | 34 SHEET AS | 1 | |
| 2866276 | LINER | 1 | |
| 2866292 | 35 DOOR AS | 1 | |
| 2866295 | 36 DOOR AS | 1 | |
| 2737638 | LINER | 1 | |
| 2866298 | 37 COVER GP-ACCESS (HYDRAULIC TANK) | 1 | |
| 2866303 | 38 DOOR GP-ACCESS (RADIATOR) | 1 | |
| 2936982 | 39 SHEET AS | 1 | |
| 2983282 | 40 SCREEN AS (HOOD, LH) | 1 | |
| 2983288 | 41 SCREEN AS (UPPER, REAR, LH) | 1 | |
| 2983294 | 42 SCREEN AS (RADIATOR DOOR, REAR) | 1 | |
| 2896464 | 43 HOOD GP-ENGINE | 1 | |
| 2896475 | 44 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 9 | |
| 9R2060 | BOSS (M10X1.5X21-MM) | 2 | |
| 2896479 | 45 SUPPORT AS | 1 | |
| 1021173 | GUARD (15-CM) | ||
| 2448198 | LINER | 1 | |
| 2896484 | 46 SUPPORT AS-ENCLOSURE | 1 | |
| 2448278 | LINER | 1 | |
| 2448288 | LINER | 1 | |
| 2896491 | 47 SUPPORT AS | 1 | |
| 2488943 | LINER | 1 | |
| 2896497 | 48 SUPPORT AS | 1 | |
| 2896501 | 49 SUPPORT AS | 1 | |
| 2896503 | 50 SUPPORT AS | 1 | |
| 2896506 | 51 SUPPORT AS | 1 | |
| 2896512 | 52 SUPPORT AS | 1 | |
| 2783832 | LINER | 1 | |
| 2896518 | 53 SUPPORT AS | 1 | |
| 2896522 | 54 SUPPORT AS | 1 | |
| 2896529 | 55 SUPPORT AS | 1 | |
| 2896531 | 56 SUPPORT AS | 1 | |
| 2896535 | 57 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896538 | 58 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896542 | 59 SHEET AS | 1 | |
| 2896544 | 60 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896547 | 61 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896549 | 62 SHEET AS | 1 | |
| 2622365 | LINER | 1 | |
| 2896556 | 63 HANDRAIL AS | 1 | |
| 2896559 | 64 HANDRAIL AS | 1 | |
| 2896562 | 65 SHIM (1-MM THK) | 2 | |
| 2896567 | 66 BRACKET | 3 | |
| 2896572 | 67 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3B4618 | 68 PIN-COTTER | 4 | |
| 1146285 | 69 BAR | 2 | |
| 1331371 | 70 BAR | 3 | |
| 2M5795 | 71 PIN-CLEVIS | 1 | |
| 3B4607 | 72 PIN-COTTER | 1 | |
| 5P1076 | 73 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 5P4115 | 74 WASHER-HARD (7.2X19X2-MM THK) | 12 | |
| 6V7744 | 75 LOCKNUT (M10X1.5-THD) | 4 | |
| 7Y2854 | 76 SPACER (24X38X3-MM THK) | 8 | |
| 8T0328 | 77 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 8T4121 | 78 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 79 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4138 | 80 BOLT (M6X1X20-MM) | 16 | |
| 8T4189 | 81 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 82 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 83 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 84 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4910 | 85 BOLT (M12X1.75X60-MM) | 10 | |
| 8T6693 | 86 SCREW-MACHINE (M5X0.8X16-MM) | 4 | |
| 9X8256 | 87 WASHER (6.6X12X2-MM THK) | 4 | |
| 3077700 | 88 SHEET AS-SOUND SUPPRESSION | 1 | |
| 6P2216 | CAP (PUSH ON) | 3 | |
| 3077702 | INSULATION | 1 |
