System And Components
375-3016 HOOD & GUARD GPS/N BWW177-254
Group No: 375-3016
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1384 | 1 BUMPER-CONICAL | 6 | |
| 4I0118 | 2 HOOK AS | 2 | |
| 4I2599 | 3 SOCKET | 3 | |
| 5P0540 | 4 NUT-HEX FULL (9/16-18-THD) | 4 | |
| 2462641 | 5 PADLOCK GP | 2 | |
| 5P8500 | KEY (CORPORATE) | 1 | |
| 7Y2853 | 6 SPACER (13X38X5-MM THK) | 8 | |
| 8T1578 | 7 PAWL (LATCH) | 2 | |
| 8Y4000 | 8 LATCH AS (T-BAR, COMPARTMENT) | 2 | |
| 9M3835 | 9 LATCH-RUBBER | 1 | |
| 0964129 | 10 CUSHION | 2 | |
| 1161628 | 11 SUPPORT AS | 1 | |
| 1224120 | 12 ROD | 6 | |
| 1313954 | 13 BRACKET AS | 3 | |
| 1313957 | 14 BAR | 2 | |
| 1358573 | 15 BOLT AS | 50 | |
| 1358575 | 16 BOLT AS | 27 | |
| 1358577 | 17 BOLT AS | 36 | |
| 1358578 | 18 BOLT AS | 6 | |
| 1703016 | 19 SPACER (19X32X2-MM THK) | 13 | |
| 1848423 | 20 SUPPORT AS | 1 | |
| 2034889 | 21 SPRING | 1 | |
| 2034890 | 22 SPRING | 1 | |
| 2265929 | 23 SHIM (3-MM THK) | 1 | |
| 2448207 | 24 COVER AS | 1 | |
| 2622324 | 25 COVER AS | 1 | |
| 2866220 | 26 SHEET AS | 1 | |
| 2866276 | LINER | 1 | |
| 2866298 | 27 COVER GP-ACCESS (HYDRAULIC TANK) | 1 | |
| 2896475 | 28 SUPPORT AS | 1 | |
| 2896479 | 29 SUPPORT AS | 1 | |
| 1021173 | GUARD (15-CM) | ||
| 2448198 | LINER | 1 | |
| 2896491 | 30 SUPPORT AS | 1 | |
| 2488943 | LINER | 1 | |
| 2896497 | 31 SUPPORT AS | 1 | |
| 2896501 | 32 SUPPORT AS | 1 | |
| 2896503 | 33 SUPPORT AS | 1 | |
| 2896512 | 34 SUPPORT AS | 1 | |
| 2783832 | LINER | 1 | |
| 2896522 | 35 SUPPORT AS | 1 | |
| 2896529 | 36 SUPPORT AS | 1 | |
| 2896531 | 37 SUPPORT AS | 1 | |
| 2896535 | 38 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896542 | 39 SHEET AS | 1 | |
| 2896544 | 40 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896547 | 41 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896549 | 42 SHEET AS | 1 | |
| 2622365 | LINER | 1 | |
| 2896556 | 43 HANDRAIL AS | 1 | |
| 2896559 | 44 HANDRAIL AS | 1 | |
| 2896562 | 45 SHIM (1-MM THK) | 2 | |
| 2896572 | 46 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2936982 | 47 SHEET AS | 1 | |
| 2937056 | 48 SHEET AS | 1 | |
| 3077700 | 49 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 2 | |
| 6P2216 | CAP (PUSH ON) | 2 | |
| 3077702 | INSULATION | 1 | |
| 3185928 | 50 COVER AS | 1 | |
| 3253984 | INSULATION | 1 | |
| 3273122 | 51 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3273123 | 52 SUPPORT AS | 1 | |
| 2770886 | LINER | 1 | |
| 3273126 | 53 SUPPORT | 1 | |
| 3273159 | 54 DOOR AS-ACCESS (BATTERY COMPARTMENT) | 1 | |
| 3273162 | 55 DOOR AS-ACCESS (MAIN HYDRAULIC PUMP) | 1 | |
| 3364485 | 56 SUPPORT AS | 1 | |
| 3589701 | 57 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3666481 | 58 SUPPORT AS | 1 | |
| 3727627 | 59 COVER AS-ACCESS | 1 | |
| 3727634 | 60 COVER AS | 1 | |
| 3758652 | 61 HOOD GP-ENGINE | 1 | |
| 3758656 | 62 DOOR GP-ACCESS (AIR CLEANER, RADIATOR) | 1 | |
| 3758680 | 63 LINER | 2 | |
| 3758681 | 64 LINER | 1 | |
| 3758749 | 65 LATCH AS | 1 | |
| 3758750 | 66 LATCH AS | 1 | |
| 3758760 | 67 LINER | 1 | |
| 3758761 | 68 LINER | 1 | |
| 1146285 | 69 BAR | 2 | |
| 1331371 | 70 BAR | 3 | |
| 2M5795 | 71 PIN-CLEVIS | 1 | |
| 3B4607 | 72 PIN-COTTER | 1 | |
| 3B4618 | 73 PIN-COTTER | 7 | |
| 5C7261 | 74 NUT (M8X1.25-THD) | 6 | |
| 5P1076 | 75 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 5P4115 | 76 WASHER-HARD (7.2X19X2-MM THK) | 12 | |
| 6V7744 | 77 LOCKNUT (M10X1.5-THD) | 4 | |
| 7Y2854 | 78 SPACER (24X38X3-MM THK) | 8 | |
| 8T0328 | 79 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 8T4121 | 80 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 81 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4138 | 82 BOLT (M6X1X20-MM) | 16 | |
| 8T4189 | 83 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 84 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 85 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 86 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4910 | 87 BOLT (M12X1.75X60-MM) | 10 | |
| 8T6693 | 88 SCREW-MACHINE (M5X0.8X16-MM) | 4 | |
| 9X8256 | 89 WASHER (6.6X12X2-MM THK) | 4 |
