System And Components
230-7216 BELT TENSIONER GPS/N TXF1-UP; MHX6053-UP
Group No: 230-7216
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1979642 | 1 PULLEY AS-IDLER (8-GROOVE) | 1 | |
| 2117895 | 2 BELT TENSIONER | 1 | |
| 2278313 | 3 PULLEY AS-IDLER (8-GROOVE) | 1 | |
| 2303207 | 4 BRACKET-SUPPORT | 1 | |
| 2431557 | 5 BRACKET | 1 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V2317 | 7 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 3 | |
| 6V5842 | 9 BOLT (M10X1.5X40-MM) | 3 | |
| 6V8149 | 10 NUT (M12X1.75-THD) | 2 | |
| 8T0646 | 11 BOLT (M12X1.75X110-MM) | 2 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4178 | 13 BOLT (M10X1.5X90-MM) | 1 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 |
