307-4848 LINES GP-BOOM CYLINDERS/N P5D1-UP

Group No: 307-4848

Part Number	Part Name	Qty
9F2167	1 SCREW-PURGE (3/8-24X1.164-IN)	1
1132004	2 BOLT-SOCKET HEAD (M12X1.75X45-MM)	4
1021174	3 GUARD (10-CM EACH)
1287591	4 SUPPORT AS	1
1708553	5 BOLT-SOCKET HEAD (M12X1.75X40-MM)	4
2218859	6 SENSOR AS-PRESSURE (BOOM LOWERING CONTROL)	1
1710596	RECEPTACLE AS-CONNECTOR (3-PIN)	1
3E3371	WEDGE-RECEPTACLE LOCK (3-PIN)	1
3K0360	SEAL-O-RING	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	3
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	3
2344492	7 SUPPORT	1
2927367	8 FLANGE	1
3258858	9 HOSE AS	4
3100147	10 VALVE GP-LOAD CONTROL	1
3302314	11 TUBE AS	1
3199717	12 TUBE AS	1
3258787	13 TUBE AS	1
3199719	14 SUPPORT AS	1
3199721	15 SUPPORT AS	1
3543819	16 HOSE AS	1
3543813	17 HOSE AS	1
3199727	18 HOSE AS	1
3199798	19 SUPPORT AS	1
1017397	20 BOLT-SOCKET HEAD (M12X1.75X50-MM)	4
1083819	21 BOLT-SOCKET HEAD (M12X1.75X70-MM)	4
1087550	22 CLIP	2
1488322	23 CONNECTOR AS	1
2M9780	SEAL-O-RING	1
6V8640	CONNECTOR	1
6V9746	SEAL-O-RING	1
1488336	24 CONNECTOR AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8636	CONNECTOR	1
1488353	25 ELBOW AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V9001	ELBOW	1
8T4648	26 BOLT (M12X1.75X70-MM)	2
1P3703	27 SEAL-RECTANGULAR	10
1P3704	28 SEAL-RECTANGULAR	6
1P5767	29 FLANGE-HALF	8
5P1076	30 WASHER-HARD (13.5X30X4-MM THK)	2
6V0400	31 FLANGE-HALF	16
6V1324	32 GROMMET	1
7G3413	33 CLIP (SLOT)	1
7G3414	34 CLIP (TAB)	1
8T4136	35 BOLT (M10X1.5X25-MM)	2
8T4139	36 BOLT (M12X1.75X30-MM)	14
8T4184	37 BOLT (M12X1.75X45-MM)	18
8T4194	38 BOLT (M12X1.75X50-MM)	32
8T4223	39 WASHER-HARD (13.5X25.5X3-MM THK)	64
8T4121	40 WASHER-HARD (11X21X2.5-MM THK)	2
1092013	41 GUARD (8-CM)
