298-5110 GEAR GP-FRONTS/N C4E1-UP

Group No: 298-5110
Part NumberPart NameQty
6I02171 BOLT (M8X1.25X20-MM)6
6I06452 BOLT (M8X1.25X25-MM)4
6I06503 BOLT (M10X1.5X65-MM)3
7C46164 BOLT (M12X1.75X45-MM)1
06761795 DOWEL1
10037516 BOLT (M8X1.25X65-MM)5
10048307 BOLT (M10X1.5X20-MM)1
10138958 BOLT (M8X1.25X35-MM)2
12438159 BOLT (M8X1.25X16-MM)9
133101110 WASHER1
425710311 GEAR (68-TEETH)1
226876712 COVER AS-FRONT1
226876612A GASKET-COVER1
232366613 WASHER-THRUST1
251433614 GEAR AS-IDLER (73-TEETH)1
277301215 GASKET-COVER (HOUSING)1
324044416 HUB-IDLER GEAR1
288042217 SEAL-CRANKSHAFT1
323351518 HOUSING-FRONT1
346040819 PLATE1
2256522PLUG-CUP1
