System And Components
254-0117 MUFFLER GPS/N RBA1-UP
Group No: 254-0117
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0364 | 1 STUD (M10X1.5X45-MM) | 3 | |
| 6I0563 | 2 NUT (M10X1.5-THD) | 3 | |
| 2106829 | 3 CLAMP AS | 2 | |
| 2732585 | 4 PLATE AS | 1 | |
| 2732596 | 5 MUFFLER AS | 1 | |
| 3172728 | 6 BRACKET AS | 1 | |
| 7X0818 | 7 BOLT (M8X1.25X45-MM) | 2 | |
| 7Y1924 | 8 SPACER (9X19X23-MM THK) | 2 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4195 | 12 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 |
