System And Components
307-4410 TURBOCHARGER GPS/N C4E1-UP
Group No: 307-4410
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0593 | 2 BOLT (M10X1.5X30-MM) | 1 | |
| 6I0654 | 3 BOLT (M10X1.5X25-MM) | 1 | |
| 6I0817 | 4 ADAPTER | 1 | |
| 6I4200 | 5 BOLT (M10X1.5X16-MM) | 2 | |
| 9Y9381 | 6 WASHER-HARD | 1 | |
| 1278165 | 7 SPACER | 1 | |
| 1068916 | 8 BOLT (M6X1X16-MM) | 2 | |
| 1234038 | 9 SPACER | 1 | |
| 1724325 | 10 SPACER | 1 | |
| 3533477 | 11 GASKET-TURBOCHARGER | 1 | |
| 3533478 | 12 GASKET-TURBOCHARGER | 1 | |
| 2388292 | 13 BOLT-FLANGE HEAD | 1 | |
| 2780361 | 14 BOLT (M10X1.5X45-MM) | 3 | |
| 2947375 | 15 SOLENOID (WASTEGATE) | 1 | |
| 2984570 | 16 GASKET-EXHAUST MANIFOLD | 1 | |
| 3032116 | 17 CLIP | 1 | |
| 3160555 | 18 TURBOCHARGER | 1 | |
| 3838543 | 19 TUBE AS-TURBOCHARGER OIL | 1 | |
| 3838542 | 19A CLIP-PIPE | 1 | |
| 2258524 | 19B BOLT-SPECIAL (M10X1.5X23-MM) | 2 | |
| 2258526 | 19C WASHER (10.4X13.75X1.37-MM THK) | 4 | |
| 3035787 | 20 TUBE AS-TURBOCHARGER OIL (DRAIN) | 1 | |
| 1032135 | 20A CLIP | 1 | |
| 3035788 | 21 MANIFOLD-EXHAUST | 1 | |
| 3035793 | 22 TUBE AS | 1 | |
| 4B8774 | 22A NUT-FLARED | 1 | |
| 0328047 | 22B FERRULE | 1 | |
| 2780316 | 22C CLIP | 2 | |
| 3006520 | 22D HOSE AS | 1 | |
| 1072348 | 22E CLIP | 2 | |
| 3043704 | 23 TUBE AS | 1 | |
| 0328047 | 23A FERRULE | 2 | |
| 4B8774 | 23B NUT-FLARED | 1 | |
| 0358014 | 23C NUT | 1 | |
| 1339469 | 23D CLIP | 2 | |
| 1945390 | 24 GASKET-MANIFOLD | 1 | |
| 3617519 | 25 ROD-THREADED | 4 | |
| 6I0563 | 26 NUT (M10X1.5-THD) | 4 |
