System And Components
254-0119 LINES GP-FUELS/N RBA1-UP
Group No: 254-0119
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6S8620 | 1 CLAMP-HOSE | 12 | |
| 1757739 | 2 CLAMP | 2 | |
| 2735684 | 3 TUBE AS | 1 | |
| 2735685 | 4 TUBE AS | 1 | |
| 2737180 | 5 BRACKET AS | 1 | |
| 2743866 | 6 CONNECTOR AS | 1 | |
| 2287100 | SEAL-O-RING | 1 | |
| 3218626 | CONNECTOR | 1 | |
| 2743867 | 7 CONNECTOR AS | 1 | |
| 2287102 | SEAL-O-RING | 1 | |
| 3218627 | CONNECTOR | 1 | |
| 2743868 | 8 ELBOW AS | 1 | |
| 2287102 | SEAL-O-RING | 1 | |
| 3218628 | ELBOW | 1 | |
| 3072032 | 9 TUBE | 2 | |
| 1195708 | 10 CLIP | 3 | |
| 1644225 | 11 CLIP | 1 | |
| 3188064 | 12 FILTER GP-WATER SEP & FUEL | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 2 | |
| 5P9297 | 14 CLIP (LOOP) | 3 | |
| 8M2773 | 15 CLIP (LOOP) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4192 | 19 BOLT (M12X1.75X25-MM) | 3 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T7547 | 22 BOLT (M8X1.25X30-MM) | 2 | |
| 5P1442 | 23 HOSE (24-CM) | ||
| 5P1442 | 23A HOSE (84-CM) | ||
| 5P1442 | 23B HOSE (40-CM) | ||
| 5P1442 | 23C HOSE (36-CM) | ||
| 5P1442 | 23D HOSE (59-CM) | ||
| 5P1442 | 23E HOSE (99-CM) |
