System And Components
254-0107 HOOD & GUARD GPS/N RBA1-UP
Group No: 254-0107
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6600 | 1 SEAL (25-CM) | ||
| 6V1580 | 2 SEAL (0.5-M) | ||
| 2147915 | 3 FILM-INSTRUCTION (ENGINE SHUTOFF) | 1 | |
| 2471080 | 4 BUMPER AS | 2 | |
| 2701577 | 5 HOOD GP-ENGINE | 1 | |
| 2701645 | 6 COWLING | 1 | |
| 2702629 | 7 GRILL | 1 | |
| 2702630 | 8 GUARD AS | 1 | |
| 2709043 | 9 BRACE | 1 | |
| 2949538 | 10 ENCLOSURE GP-ENGINE (RH) | 1 | |
| 2949539 | 11 ENCLOSURE GP-ENGINE (LH) | 1 | |
| 5C7261 | 12 NUT (M8X1.25-THD) | 1 | |
| 7X0579 | 13 WASHER-HARD (8.8X25.5X2-MM THK) | 8 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4189 | 17 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4779 | 18 BOLT (M16X2X35-MM) | 4 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4197 | 20 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T7547 | 23 BOLT (M8X1.25X30-MM) | 5 | |
| 9X8257 | 24 WASHER (17.5X30X3.5-MM THK) | 4 |
