System And Components
254-0122 LINES GP-RIDE CONTROLS/N RBA1-UP
Group No: 254-0122
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1527740 | 1 HOSE AS | 1 | |
| 3453672 | 2 ACCUMULATOR GP-RIDE CONTROL (CHARGED) | 1 | |
| 2458780 | 3 MANIFOLD GP-RIDE CONTROL | 1 | |
| 3943245 | 4 BRACKET AS | 1 | |
| 2762334 | 5 FILM-WARNING (HIGH PRESS CYLINDER, READ OMM)(ISO) | 1 | |
| 2795016 | FILM-WARNING (HIGH PRESS CYLINDER, READ OMM)(U.S.) | 1 | |
| 0965866 | 7 BOLT (M8X1.25X75-MM) | 2 | |
| 2863018 | 8 CLIP (SLOT) | 2 | |
| 2863019 | 9 CLIP (TAB) | 2 | |
| 1488318 | 10 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488340 | 11 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488345 | 12 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488370 | 13 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488372 | 14 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488416 | 15 REDUCER AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8939 | REDUCER-O-RING | 1 | |
| 1645549 | 16 COUPLING AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4I6287 | COUPLING | 1 | |
| 6V8555 | 17 NUT-FACE SEAL (1-14-THD) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4956 | 20 BOLT (M12X1.75X35-MM) | 2 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 7X0605 | 23 WASHER-HARD (13X28X1.6-MM THK) | 2 | |
| 2101967 | 24 HOSE AS | 1 |
