System And Components
384-9980 AIR CLEANER GPS/N HJR1-UP
Group No: 384-9980 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2566453 | 1 SENSOR-TEMPERATURE (2-PIN)(INTAKE AIR) | 1 | |
| 2764836 | 2 SWITCH-PRESSURE (24-VOLT)(AIR CLEANER) | 1 | |
| 3233309 | 3 CAP | 2 | |
| 3393043 | 4 DUCT-AIR | 1 | |
| 3435643 | 5 AIR CLEANER GP | 1 | |
| 3678073 | 6 SEAL | 1 | |
| 3850042 | 7 HOSE | 1 | |
| 3855066 | 8 SUPPORT AS | 1 | |
| 3997014 | 9 PLATE-INSTRUCTION (LUBRICATION POINTS) | 1 | |
| 2428009 | 10 SCREW-PAN HEAD (6-19X0.5-IN) | 2 | |
| 5C9553 | 11 BOLT (M6X1X16-MM) | 4 | |
| 5P1717 | 12 CLAMP-HOSE | 1 | |
| 5P4116 | 13 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7F2050 | 14 LOCKNUT (3/4-16-THD) | 1 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 2 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 2 | |
| 8T4908 | 17 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4985 | 18 CLAMP-HOSE | 1 | |
| 9X6165 | 19 WASHER (6.5X22X2.5-MM THK) | 4 |
