System And Components
385-6811 COVER GP-EXHAUSTS/N HJR1-UP
Group No: 385-6811 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1294741 | 1 LATCH AS-T-BAR | 1 | |
| 2572250 | 2 WASHER (5X38-MM DIA) | 4 | |
| 4362253 | 3 RING | 1 | |
| 3856812 | 4 COVER AS | 1 | |
| 3856823 | 5 STEP AS | 1 | |
| 3856824 | 6 COVER AS | 1 | |
| 3856825 | 7 COVER AS-BATTERY | 1 | |
| 3856826 | 8 COVER AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 2 | |
| 1599541 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3856827 | 9 COVER AS | 1 | |
| 3856828 | 10 TREAD-NONSKID | 1 | |
| 3856829 | 11 PAWL-LATCH | 1 | |
| 3856831 | 12 COVER AS | 1 | |
| 3856833 | 13 INSULATION | 1 | |
| 3856834 | 14 INSULATION | 1 | |
| 3856837 | 15 PLATE | 2 | |
| 3856839 | 16 BRACKET | 1 | |
| 3856844 | 17 SPRING AS-GAS (EXHAUST) | 1 | |
| 3856845 | 18 FENDER | 1 | |
| 3856846 | 19 TREAD-NONSKID | 2 | |
| 4176764 | 20 INSULATION | 1 | |
| 1560283 | 21 WASHER-HARD (8.4X35X2.5-MM THK) | 3 | |
| 5C7261 | 22 NUT (M8X1.25-THD) | 3 | |
| 5P1076 | 23 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P4116 | 24 WASHER-HARD (8.8X20.5X2-MM THK) | 46 | |
| 6V7743 | 25 LOCKNUT (M6X1-THD) | 2 | |
| 7X7729 | 26 WASHER (11X25X3-MM THK) | 4 | |
| 8T4133 | 27 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4184 | 29 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4189 | 30 BOLT (M8X1.25X20-MM) | 40 | |
| 8T4200 | 31 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4205 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3E8299 | 33 SEAL (7-CM EACH) | ||
| 3E8299 | 33A SEAL (16.2-CM) | ||
| 3E8299 | 33B SEAL (13.2-CM) | ||
| 7X7898 | 34 TRIM (40-CM EACH) | ||
| 7X2537 | 35 BOLT (M8X1.25X35-MM) | 2 | |
| 9G8661 | 36 SPACER (10X16X20-MM THK) | 2 |
