System And Components
356-1150 TURBOCHARGER GPS/N C7N1-UP
Group No: 356-1150 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 3456605 | 2 GASKET | 1 | |
| 4795810 | 3 TURBOCHARGER AS | 1 | |
| 4878468 | 3A RING | 1 | |
| 5022907 | 4 LINES GP-TURBOCHARGER OIL (SUPPLY) | 1 | |
| 3564035 | 5 LINES GP-TURBOCHARGER AIR | 1 | |
| 3564041 | 6 LINES GP-TURBOCHARGER AIR (WASTEGATE) | 1 | |
| 3570617 | 7 GASKET | 1 | |
| 3570646 | 8 CLIP | 1 | |
| 3587592 | 9 GASKET | 1 | |
| 3596320 | 10 CLIP | 1 | |
| 4872925 | 11 LINE AS-OIL (DRAIN) | 1 | |
| 3594462 | 11A CLIP | 1 | |
| 3836037 | 12 SPACER (9.15X19.75X15-MM THK) | 1 | |
| 1068916 | 13 BOLT (M6X1X16-MM) | 2 | |
| 1243815 | 14 BOLT (M8X1.25X16-MM) | 3 | |
| 1475553 | 15 STUD (M10X1.5X40-MM) | 4 | |
| 6I0254 | 16 BOLT (M8X1.25X30-MM) | 1 | |
| 6I0563 | 17 NUT (M10X1.5-THD) | 4 | |
| 4578672 | 18 BOLT (M10X1X22-MM) | 1 |
