152-3385 WIRING GP-ELECTRONIC CONTROLS/N 4CW222-UP

Group No: 152-3385
Part NumberPart NameQty
4P59181 CLIP4
3S20932 STRAP-CABLE17
10517973 MOUNT7
8T41214 WASHER-HARD (11X21X2.5-MM THK)2
15822365 HARNESS AS1
1003320PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1112416PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
3E00756 SWITCH GP-MAGNETIC (24-VOLT)(HEATER)1
4P18267 WIRE AS1
8T42008 BOLT (M8X1.25X16-MM)1
8T42249 WASHER-HARD (8.8X16X2-MM THK)3
7E882810 SHIELD-HEAT1
8T497011 BOLT (M6X1X14-MM)2
9X825612 WASHER (6.6X12X2-MM THK)2
7E571413 STRAP-GROUNDING1
7X253614 BOLT (M8X1.25X14-MM)2
4P813415 CLIP (LADDER)2
8T413716 BOLT (M10X1.5X20-MM)2
7K118117 STRAP-CABLE2
