System And Components
4P-5433 AIR COMPRESSOR ASPART OF 7E-2303 AIR COMPRESSOR GP
Group No: 4P-5433
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P4358 | 1 FLANGE | 1 | |
| 6D1004 | 2 GASKET | 1 | |
| 7M7410 | 3 PLUG-PIPE | 2 | |
| 1D4540 | 4 BOLT (5/16-18X2.75-IN) | 4 | |
| 8T6757 | 5 PLUG-PIPE | 3 | |
| 6V0387 | 6 PLUG-PIPE | 2 | |
| 0S1617 | 7 BOLT (5/16-18X0.75-IN) | 4 | |
| 3B4505 | 8 LOCKWASHER | 8 | |
| 6I2124 | 9 COVER-BOTTOM | 1 | |
| 6I2123 | 10 GASKET | 1 | |
| 6I2127 | 11 ADAPTER-REAR | 1 | |
| 6V1820 | 12 BOLT (M10X1.5X30-MM) | 2 | |
| 6V5839 | 13 WASHER (11X21X2.5-MM THK) | 2 | |
| 5P3114 | 14 SEAL-O-RING | 1 | |
| 0328087 | 15 STUD | 4 | |
| 6V8186 | 16 NUT-FULL (5/16-24-THD) | 4 | |
| 6I2126 | 17 ADAPTER | 1 | |
| 3F8156 | 18 BOLT-SOCKET HEAD | 1 | |
| 7C0577 | 19 GASKET-CYLINDER HEAD | 1 | |
| 1082522 | 20 CYLINDER HEAD AS | 1 | |
| 7C0570 | KIT-PISTON RING (AIR COMPRESSOR) | 1 | |
| 7C0571 | KIT-UNLOADER (AIR COMPRESSOR) | 1 | |
| 6I2125 | KIT-PISTON (AIR COMPRESSOR) | 1 | |
| 1070260 | KIT-MAJOR REPAIR (AIR COMPRESSOR) | 1 |
