System And Components
4P-3368 WIRING GP-HEATERS/N 2BK18836-UP
Group No: 4P-3368
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E9958 | 1 MODULE AS-CONTROL | 1 | |
| 4P1443 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 7E4512 | 3 BRACKET | 1 | |
| 3E0074 | 4 SWITCH AS-MAGNETIC (HEATER) | 1 | |
| 1126646 | 5 LOCKNUT (M6X1-THD) | 1 | |
| 0039835 | 6 PROTECTOR | 2 | |
| 4P1826 | 7 WIRE AS | 1 | |
| 1125475 | 8 SWITCH-WATER TEMPERATURE | 1 | |
| 7E5602 | 9 SWITCH AS-PRESSURE (OIL) | 1 | |
| 3K0360 | 10 SEAL-O-RING | 1 | |
| 7E5714 | 11 STRAP-GROUNDING | 1 | |
| 8T4200 | 12 BOLT (M8X1.25X16-MM) | 3 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4970 | 14 BOLT (M6X1X14-MM) | 2 | |
| 8T4205 | 15 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 5C2890 | 18 NUT (M6X1-THD) | 2 | |
| 7E8828 | 19 SHIELD-HEAT | 1 | |
| 8T4191 | 20 BOLT (M10X1.5X16-MM) | 1 |
