System And Components
133-4241 VALVE GP-MAIN CONTROL -4-FUNCTIONS/N 7BS1-UP
Group No: 133-4241
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E5436 | 1 RETAINER-SPRING | 6 | |
| 6E5958 | 2 VALVE GP-CONTROL (AUXILIARY) | 1 | |
| 8F0212 | 3 SEAL-O-RING | 6 | |
| 4B4158 | 4 SCREW-DRIVE (NO 4X0.25-IN) | 1 | |
| 6E5434 | 5 HOUSING-PILOT | 6 | |
| 8T6870 | 6 BOLT (M8X1.25X70-MM) | 12 | |
| 8T4224 | 7 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 1086428 | 8 VALVE GP-RELIEF (MAIN) | 1 | |
| 1860908 | 9 VALVE GP-RELIEF (PILOT OPERATED)(LINE,AUX CYL HEAD END PORT) | 1 | |
| 1860908 | 9A VALVE GP-RELIEF (PILOT OPERATED)(LINE,AUX CYL ROD END PORT) | 1 | |
| 1860901 | 10 VALVE GP-RELIEF (LINE,TILT CYL HEAD END PORT) | 1 | |
| 1463143 | 11 STEM-TILT | 1 | |
| 1467824 | 12 STEM-TILT | 1 | |
| 1463142 | 13 STEM-LIFT | 1 | |
| 6E5457 | 14 PLUG | 3 | |
| 6E5643 | 15 VALVE (LOAD CHECK) | 3 | |
| 3D2824 | 16 SEAL-O-RING | 3 | |
| 4T3148 | 17 SPRING | 3 | |
| 1860912 | 18 VALVE GP-RELIEF (LINE,TILT CYL ROD END PORT) | 1 | |
| 6E5431 | 19 SHIM (0.5-MM THK) | 15 | |
| 6E5437 | 20 SPRING (INNER) | 3 | |
| 6E5438 | 21 SPRING (OUTER) | 3 | |
| 6E5439 | 22 SPRING (INNER) | 3 | |
| 6E5440 | 23 SPRING (OUTER) | 3 | |
| 9T7634 | 24 VALVE GP-CHECK (MAKEUP) | 1 |
