System And Components
245-1736 TORQUE CONVERTER GPS/N T1C1-UP
Group No: 245-1736
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1644219 | 1 HOUSING-ROTATING | 1 | |
| 1355557 | 2 IMPELLER-CONVERTER | 1 | |
| 1541205 | 3 HUB-IMPELLER | 1 | |
| 1539204 | 4 GEAR-DRIVE (51-TEETH) | 1 | |
| 7M8514 | 5 RING-RETAINING | 1 | |
| 2260755 | 6 SHAFT AS | 1 | |
| 2246952 | BUSHING | 1 | |
| 2379354 | 7 RACE-SPECIAL THRUST | 2 | |
| 1T1356 | 8 RING-SEAL | 1 | |
| 2372859 | 9 BEARING-ROLLER | 1 | |
| 2372802 | 10 RING-SEAL | 3 | |
| 1543060 | 11 RACE-ROLLER BEARING | 1 | |
| 1724311 | 12 BEARING-SPECIAL RACE | 1 | |
| 1539207 | 13 CARRIER | 1 | |
| 9F7383 | 14 RING-METAL SEAL | 1 | |
| 5P1982 | 15 RING-RETAINING | 1 | |
| 6V1820 | 16 BOLT (M10X1.5X30-MM) | 48 | |
| 6V5839 | 17 WASHER (11X21X2.5-MM THK) | 54 | |
| 1352653 | 18 SEAL-O-RING | 1 | |
| 1567239 | 19 STATOR | 1 | |
| 7G7541 | 20 TURBINE-CONVERTER | 1 | |
| 1T1282 | 21 RACE-THRUST BEARING | 2 | |
| 8B7789 | 22 RING-SNAP | 2 | |
| 6V9670 | 23 SEAL-O-RING | 1 | |
| 2617692 | 24 DISC-FRICTION | 1 | |
| 1644220 | 25 PISTON | 1 | |
| 2S1362 | 26 RING-SEAL | 1 | |
| 1S6515 | 27 RING-SEAL | 1 | |
| 2464384 | 28 COUPLING AS | 1 | |
| 1A2029 | BOLT (3/8-16X1.125-IN) | 12 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 12 | |
| 2470866 | SPRING | 12 | |
| 2470867 | SPRING | 6 | |
| 2470868 | SPRING | 6 | |
| 1644222 | 29 PILOT-FLYWHEEL | 1 | |
| 6V9191 | 30 BALL BEARING | 1 | |
| 1T1616 | 31 WASHER-SPRING (54.9X86.4X6.1-MM) | 1 | |
| 3T8670 | 32 RETAINER | 1 | |
| 8T9515 | 33 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 20 | |
| 8B2327 | 34 RING-RETAINING | 1 | |
| 2202696 | 35 CARRIER AS | 1 | |
| 4B9783 | BALL | 4 | |
| 6V3918 | 36 BOLT (M8X1.25X50-MM) | 3 | |
| 1355561 | 37 HUB | 1 | |
| 1T1278 | 38 BEARING-THRUST | 2 | |
| 1352654 | 39 SEAL-O-RING | 1 | |
| 1T1281 | 40 RETAINER-BEARING | 2 | |
| 1T1590 | 41 RACE-FREEWHEEL | 1 | |
| 2843599 | 42 CAM-FREEWHEEL | 1 | |
| 8T0273 | 43 BOLT-SOCKET HEAD (M12X1.75X40-MM) | 8 | |
| 6V1902 | 44 SEAL-O-RING | 1 | |
| 1T0679 | 45 ROLLER-FREEWHEEL | 11 | |
| 1T0680 | 46 SPRING-FREEWHEEL | 11 | |
| 1T1589 | 47 RACE-THRUST BEARING | 2 | |
| 6V4248 | 48 BOLT (M10X1.5X25-MM) | 6 | |
| 1646163 | 49 HOUSING AS | 1 | |
| 4N2514 | GEAR (113-TEETH) | 1 |
