Assembly
100%

5E-5895 FRAME GP-MAINS/N 7GG374-UP

Group No: 5E-5895
Part NumberPart NameQty
11549051 BUMPER GP-DRUM1
10541182 BEARING2
11490453 YOKE AS1
1047047SHAFT1
3E98624 LOCKNUT (3/4-10-THD)12
7X05875 WASHER-HARD (17X54X3-MM THK)1
11490446 SCRAPER GP-SMOOTH DRUM1
7X05407 WASHER-HARD (17X90X10-MM THK)2
10470248 PLATE1
7X04109 BOLT (1-8X4-IN)8
8T5361WASHER-HARD (28X49X5-MM THK)8
7X803210 SPACER (1.2-MM THK)2
7X8033SPACER (1.6-MM THK)2
7X8034SPACER2
1055446SPACER2
1055441SPACER2
7X803011 PIN AS-STEERING LOCK1
0776627SCREW-DRIVE (NO 12X12.7-MM)2
7R0041CHAIN1
3B848912 FITTING-GREASE (1/8-27 PTF)1
114095913 SPACER (1.2-MM THK)2
6R4354SPACER (2-MM THK)2
6R4356SPACER (3.5-MM THK)2
1G5369SPACER (0.8-MM THK)2
5J642414 BEARING2
3B848515 ELBOW1
3B848816 FITTING-GREASE (1/8-27 PTF)2
114097617 FRAME AS-MAIN1
7X037318 BOLT (3/4-10X5.5-IN)2
109580419 PIVOT AS-STEERING1
7X034320 BOLT (5/8-11X1.25-IN)2
6R435221 BUSHING-TENSION4
5E989222 PIN1
1G537323 PIN-STEERING PIVOT2
4L645424 BOLT (3/8-16X1-IN)4
8T489625 WASHER-HARD (10.2X18.5X2.5-MM THK)4
122150326 PLATE2
