System And Components
361-2987 PANEL GP-INSTRUMENTS/N BDN1-UP
Group No: 361-2987
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V7087 | 1 LENS-AMBER | 1 | |
| 2V7088 | 2 LENS-RED | 1 | |
| 3S2093 | 3 STRAP-CABLE | 4 | |
| 5P8500 | 4 KEY | 1 | |
| 8C6354 | 5 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8L9801 | 6 LAMP (12-VOLT) | 2 | |
| 1560518 | 7 SOCKET AS | 2 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1673593 | 8 STRAP | 1 | |
| 2423283 | 9 LAMP AS-LED (12-VOLT, RED) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3012980 | 10 SWITCH AS-TOGGLE (ROTOR TURNING)(IDLE, HIGH, LOW) | 1 | |
| 3612988 | 11 PLATE | 1 | |
| 3612989 | 12 HARNESS AS-PANEL | 1 | |
| 3623512 | 13 PLUG-ILLUMINATED | 1 | |
| 4258936 | 14 SWITCH AS-ROCKER (PERMIT HIGHER IDLE) | 1 | |
| 3624720 | 15 SWITCH AS-ROCKER (DPF REGENERATION INHIBIT) | 1 | |
| 3677786 | 16 DISPLAY GP-MONITOR | 1 | |
| 3848311 | 17 FILM-INSTRUMENT | 1 | |
| 0965962 | 18 WASHER-HARD (3.4X7X0.8-MM THK) | 4 | |
| 1893158 | 19 SUPPRESSOR-ARC | 1 | |
| 3C6969 | 20 NUT (M3X0.5-THD) | 4 | |
| 3E0156 | 21 SWITCH GP-START (ENGINE) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 9B7233 | LOCKWASHER | 1 | |
| 6V9671 | 22 SCREW-MACHINE (M3X0.5X12-MM) | 4 |
