System And Components
322-3643 AIR COMPRESSOR GPS/N NGH1-UP
Group No: 322-3643
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2255222 | 1 VALVE AS-PRESSURE RELIEF (AIR COMPRESSOR) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 2903468 | 2 AIR COMPRESSOR GP | 1 | |
| 3139145 | 3 BRACKET AS | 1 | |
| 3139146 | 4 TUBE AS | 1 | |
| 9X2040 | 5 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 2 | |
| 0307946 | 6 ELBOW | 1 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V4248 | 8 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5048 | 9 SEAL-O-RING | 1 | |
| 6V5839 | 10 WASHER (11X21X2.5-MM THK) | 3 | |
| 6V8260 | 11 SEAL-O-RING | 1 | |
| 6V8336 | 12 BOLT (M12X1.75X70-MM) | 2 | |
| 8M2772 | 13 CLIP (LOOP) | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 2 |
