System And Components
102-9282 SHUTOFF GP-ELECTRICALS/N 6NB1-UP
Group No: 102-9282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1275 | 1 LOCKWIRE (20-CM) | ||
| 8S8158 | 2 SEAL-WIRE | 1 | |
| 5S0003 | 3 NUT (5/16-18-THD) | 4 | |
| 0S1618 | 4 BOLT (5/16-18X1-IN) | 4 | |
| 9M1974 | 5 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 1 | |
| 6V8801 | 7 NUT (3/8-16-THD) | 1 | |
| 5M2894 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 4D1326 | 9 LOCKWASHER | 1 | |
| 0307946 | 10 ELBOW | 1 | |
| 3J7354 | 11 SEAL-O-RING | 1 | |
| 2V5956 | 12 HOSE AS | 1 | |
| 1690454 | 13 BUSHING-REDUCER | 1 | |
| 5P4479 | 14 ELBOW (FLARED-LONG) | 1 | |
| 4P8134 | 15 CLIP (LADDER) | 21 | |
| 9X6772 | 16 STRAP-CABLE | 22 | |
| 9G9151 | 17 CLIP | 2 | |
| 5N8943 | 18 ADAPTER | 1 | |
| 9G9150 | 19 CLIP | 1 | |
| 8N5626 | 20 MOUNTING GP-CONTACTOR | 1 | |
| 4P7345 | 21 SWITCH AS-TEMPERATURE (WATER TEMPERATURE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1L5620 | 22 ADAPTER | 1 | |
| 7W3355 | 23 SENSOR GP-SPEED | 1 | |
| 0L1351 | 24 BOLT (3/8-16X0.875-IN) | 2 | |
| 0L1143 | 25 BOLT (3/8-16X2.5-IN) | 1 | |
| 3L3825 | 26 SPACER (0.493X0.675X1.375-IN THK) | 1 |
