System And Components
257-5889 BOX GP-CONTROL PANELS/N 4KC654-UP
Group No: 257-5889
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V7088 | 1 LENS-RED (ENGINE FAILURE) | 1 | |
| 3E1813 | 2 SWITCH AS-PUSH BUTTON (LIGHTED)(PRELUBRICATION) | 1 | |
| 3E1814 | LAMP (24-VOLT) | 1 | |
| 3S2093 | 3 STRAP-CABLE | 8 | |
| 6V4354 | 4 SCREW-BUTTON HEAD | 4 | |
| 7C4910 | 5 SEAL | 1 | |
| 7E0860 | 6 DIAL-CONCENTRIC | 1 | |
| 3407298 | 7 CAP AS-PROTECTION | 1 | |
| 8L8413 | 8 STRAP-CABLE (WHITE) | 4 | |
| 1735413 | 9 CLAMP | 2 | |
| 1096507 | 10 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 3981723 | NUT (3/16X18-THD) | 1 | |
| 1103890 | 11 TERMINAL | 3 | |
| 1103891 | 12 COVER-END | 2 | |
| 1111324 | 13 BLOCK-CONTACT (1-POLE) | 1 | |
| 1151322 | 14 TERMINAL (DOUBLE) | 55 | |
| 1152538 | 15 COVER-END | 13 | |
| 1165270 | 16 LAMP (24-VOLT)(RED) | 1 | |
| 1243176 | 17 COVER | 1 | |
| 2702679 | 18 LOCKWASHER | 1 | |
| 3392958 | 19 GASKET | 1 | |
| 2039007 | 20 NUT (1-1/2-18-THD) | 1 | |
| 1535040 | 21 LAMP-INDICATOR (24-VOLT)(GREEN) | 1 | |
| 1631883 | 22 LAMP-INDICATOR (24-VOLT)(AMBER) | 1 | |
| 1560518 | 23 SOCKET AS | 3 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1560519 | 24 LENS-AMBER (ALARM) | 1 | |
| 1560520 | 25 LENS-GREEN (ENGINE ON) | 1 | |
| 1972691 | 26 STRIP-CONTACT | 1 | |
| 1976949 | 27 STRIP-CONTACT | 1 | |
| 2971405 | 28 MODULE GP-KEYPAD (ENGINE MONITORING SYSTEM) | 1 | |
| 2086049 | 29 TAG-IDENTIFICATION | 1 | |
| 2212304 | 30 SWITCH AS-ROTARY (ENGINE CONTROL) | 1 | |
| 2212498 | 31 WIRE AS (8-GA, BLACK) | 1 | |
| 2354861 | 32 TERMINAL-GROUND | 1 | |
| 3435650 | 33 GASKET | 1 | |
| 3410616 | 34 BOX GP-CONTROL | 1 | |
| 2578837 | 35 HARNESS AS-MONITOR (ADVISOR) | 1 | |
| 3410615 | 37 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 3615989 | 38 HARNESS AS-CONTROL (SERVICE TOOL) | 1 | |
| 2595812 | 39 MOUNTING GP-CONTROL (ENGINE MONITORING SYSTEM) | 2 | |
| 2600405 | 39A BRACKET AS | 1 | |
| 2600406 | 39B BOLT (1/4-20X1.5-IN) | 2 | |
| 2600407 | 39C CAP | 2 | |
| 4B4863 | 40 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 5P0537 | 41 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 6D5801 | 42 LOCKNUT (8-32-THD) | 4 | |
| 8T0639 | 44 BOLT (M6X1X12-MM) | 4 | |
| 3E9865 | 45 LOCKNUT (1/4-20-THD) | 2 | |
| 9X8256 | 46 WASHER (6.6X12X2-MM THK) | 4 | |
| 3425816 | 47 GASKET | 1 | |
| 3435651 | 48 GASKET | 1 | |
| 2579933 | 49 DISPLAY GP-MONITOR (ADVISOR) | 1 |
