7E-4187 PANEL GP-INSTRUMENTS/N 01Z21747-99999

Group No: 7E-4187
Part NumberPart NameQty
23226021 TACHOMETER (HOURMETER)1
23237662 PANEL1
23226053 GAUGE-TEMPERATURE (WATER/COOLANT)1
23226044 ALARM (ACTION)1
7E42905 PLUG2
6T94426 SWITCH GP-PUSH BUTTON (START)1
8T8748ADAPTER-MOUNT1
6F0253LOCKWASHER (MOUNTING)1
3K0835NUT (5/8-24-THD)1
1S0812SCREW-TAPPING2
2N23717 LAMP AS-INDICATOR (RED)(ACTION)1
2V7088LENS-RED (ACTION INDICATOR LAMP)1
6V8367LOCKWASHER (MOUNTING)1
6V8382NUT-HEX (11/16-27-THD)(MOUNTING)1
6V8817SCREW-MACHINE (4-36X4.76-IN)2
8L98018 LAMP (12-VOLT)(ACTION INDICATOR)1
7E63169 HARNESS GP-WIRING (INSTRUMENT PANEL)1
3E916110 SWITCH GP-KEY (IGNITION)1
6V8362SCREW-MACHINE (8-32X0.31-IN)2
9B7233LOCKWASHER2
9G948711 CIRCUIT BREAKER AS (10-AMPERE)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
3E738912 SWITCH-PUSH BUTTON (STOP)1
8T8748ADAPTER-MOUNT1
6F0253LOCKWASHER1
3K0835NUT (5/8-24-THD)1
1S0812SCREW-TAPPING2
3E803513 SCREW-MACHINE2
228901914 VOLTMETER (ALTERNATOR)1
232260615 GAUGE-PRESSURE (ENGINE OIL)1
1A992016 GASKET-CAP1
228902217 BEZEL1
