System And Components
131-8284 CONTROL GP-AUTO START/STOPType 2
Group No: 131-8284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2371 | 1 LAMP AS-INDICATOR (RED) | 2 | |
| 2V7088 | LENS-RED | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 6V8817 | SCREW-MACHINE (4-36X4.76-IN) | 2 | |
| 2N2372 | 2 LAMP (12-VOLT) | 3 | |
| 2V7087 | LENS-AMBER | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 6V8817 | SCREW-MACHINE (4-36X4.76-IN) | 1 | |
| 3N5716 | 3 SWITCH (PUSH BUTTON)(MAINTENANCE INDICATOR RESET) | 1 | |
| 5P8500 | 4 KEY (START) | 1 | |
| 6T7337 | 5 METER GP-SERVICE | 1 | |
| 7D0894 | 6 SCREW-HEAD | 6 | |
| 0302266 | 7 SWITCH GP-MAGNETIC (STARTER MOTOR-12V) | 1 | |
| 1096507 | 8 SWITCH AS-PUSH BUTTON (OPERATOR)(STOP) | 1 | |
| 1107887 | 9 SWITCH AS-START (KEY) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN)(START SWITCH) | ||
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1111325 | 10 BLOCK-CONTACT (2-POLE) | 1 | |
| 1243176 | 11 COVER | 1 | |
| 1266094 | 12 PLATE AS | 1 | |
| 1309376 | 13 MOUNT-FLEXIBLE | 4 | |
| 1310129 | 14 ENCLOSURE | 1 | |
| 1318308 | 15 HARNESS AS-CONTROL (AUTO START/STOP CONTROL) | 1 | |
| 1419228 | 16 LAMP AS | 1 | |
| 1422244 | 17 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 3K9520 | 18 GROMMET | 1 | |
| 3T2662 | 19 CIRCUIT BREAKER AS (15-AMPERE, AUTOMATIC RESET)(AUTO START/STOP CONTROL) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 4B1223 | 20 SCREW-MACHINE (8-32X0.875-IN) | 6 | |
| 4M5281 | 21 BOLT (1/4-20X0.75-IN) | 2 | |
| 6T3643 | 22 CIRCUIT BREAKER AS (15-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 6V1322 | 23 BOLT (1/4-20X0.375-IN) | 4 | |
| 6V8185 | 24 NUT (1/4-20-THD) | 2 | |
| 8T4205 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 8 |
