122-8946 WIRING GP-ELECTRONIC CONTROLS/N 4ES1-454

Group No: 122-8946

Part Number	Part Name	Qty
4P5918	1 CLIP	4
3S2093	2 STRAP-CABLE	17
1051797	3 MOUNT	7
1108457	4 BOOT	1
8T4121	5 WASHER-HARD (11X21X2.5-MM THK)	2
1228835	6 HARNESS AS-WIRING (ELECTRONIC CONTROL)	1
3E7278	7 SWITCH GP-MAGNETIC (AIR INLET HEATER)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
3E3365	WEDGE-RECEPTACLE LOCK (2-PIN)	1
5C2890	NUT (M6X1-THD)	2
8T8729	PIN-CONNECTOR (16-GA TO 18-GA)	2
9X1386	SLEEVE (2-CM)
4P1826	8 WIRE AS	1
5P6006	TUBE-HEAT SHRINK (9.52-MM DIA)(.1-M)
5P5675	WIRE (6-GA, BLACK)(.2-M)
9X9882	TERMINAL-RING (6-GA TO 8-GA, 1/4-IN SCREW)	2
8T4200	9 BOLT (M8X1.25X16-MM)	1
8T4224	10 WASHER-HARD (8.8X16X2-MM THK)	3
7E8828	11 SHIELD-HEAT	1
8T4970	12 BOLT (M6X1X14-MM)	2
9X8256	13 WASHER (6.6X12X2-MM THK)	2
7E5714	14 STRAP-GROUNDING	1
7X2536	15 BOLT (M8X1.25X14-MM)	2
4P8134	16 CLIP (LADDER)	2
8T4137	17 BOLT (M10X1.5X20-MM)	2
7K1181	18 STRAP-CABLE	2
0039835	19 PROTECTOR	2
1126646	20 LOCKNUT (M6X1-THD)	1
