System And Components
114-9086 AIR COMPRESSOR GPS/N 2CW1396-UP
Group No: 114-9086
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1359819 | 1 SEAL-INTEGRAL | 1 | |
| 4P5106 | 2 BRACKET | 1 | |
| 8T4136 | 3 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 4 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 6V5696 | 6 BOLT (M12X1.75X80-MM) | 2 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7C3179 | 8 GEAR (50-TEETH) | 1 | |
| 1268214 | 9 AIR COMPRESSOR GP | 1 | |
| 0907055 | 10 HOSE AS | 1 | |
| 5P4479 | 11 ELBOW (FLARED-LONG) | 1 | |
| 6B6682 | 12 NUT-FULL (3/4-16-THD) | 1 | |
| 7X0521 | 13 WASHER-HARD (20X36.5X5-MM THK) | 1 | |
| 0307946 | 14 ELBOW | 1 | |
| 3J7354 | 15 SEAL-O-RING | 1 | |
| 8T4191 | 16 BOLT (M10X1.5X16-MM) | 1 | |
| 6D3479 | 17 CLIP (LOOP) | 1 | |
| 6L1883 | 18 GASKET | 1 | |
| 4P5388 | 19 GOVERNOR-COMPRESSOR | 1 | |
| 4M6424 | 20 BOLT (5/16-18X3-IN) | 2 | |
| 4L7318 | 21 LOCKWASHER | 2 | |
| 4P5389 | 22 VALVE AS-RELIEF | 1 |
