System And Components
7E-1135 TRANSMISSION GP-MARINE2.99:1 RATIO
Group No: 7E-1135
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T6160 | 1 HOUSING AS | 1 | |
| 6V1820 | 2 BOLT (M10X1.5X30-MM) | 2 | |
| 3L7620 | 3 PLATE-IDENTIFICATION (ROTATION INDICATION)(MARINE TRANSMISSION) | 1 | |
| 4B4158 | 4 SCREW-DRIVE (NO 4X0.25-IN) | 2 | |
| 1T0477 | 5 DOWEL | 2 | |
| 6V4248 | 6 BOLT (M10X1.5X25-MM) | 5 | |
| 3T3396 | 7 EYEBOLT | 1 | |
| 2N8875 | 8 VALVE AS-SELECTOR (MARINE GEAR) | 1 | |
| 9Y5811 | 9 TUBE AS | 1 | |
| 9Y5812 | 10 GAUGE-OIL LEVEL (DIPSTICK) (MARINE TRANSMISSION) | 1 | |
| 9F2247 | 11 PLUG-PIPE | 1 | |
| 6V2316 | 12 BOLT (M8X1.25X12-MM) | 1 | |
| 9N0869 | 13 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 3S9233 | 14 SEAL-O-RING | 1 | |
| 3T2383 | 15 COVER-STRAINER | 1 | |
| 3B7721 | 16 BUSHING-REDUCER | 1 | |
| 6V4249 | 17 BOLT (M10X1.5X50-MM) | 1 | |
| 7L2227 | 18 BREATHER (MARINE GEAR) | 1 | |
| 6V1820 | 19 BOLT (M10X1.5X30-MM) | 15 | |
| 6S6031 | 20 CUP-BEARING | 1 | |
| 6S6032 | CONE-BEARING | 1 | |
| 3T2433 | 21 TUBE-CONNECTOR | 2 | |
| 2D9190 | 22 CUP-BEARING | 1 | |
| 1T1580 | CONE-BEARING | 1 | |
| 3T2402 | 23 PUMP-OIL | 1 | |
| 6V3821 | 24 BOLT (M8X1.25X110-MM) | 4 | |
| 6L9736 | 25 RING-PISTON | 2 | |
| 2N8870 | 26 GASKET-PUMP MOUNTING | 1 | |
| 3T2391 | 27 MOUNT | 1 | |
| 7T1444 | 28 PINION AS | 1 | |
| 3T2416 | 29 SHIM (0.13-MM THK) | 2 | |
| 3T2417 | SHIM (0.18-MM THK) | 2 | |
| 3T2418 | SHIM (.50MM THK) | 2 | |
| 3T2396 | 30 PISTON-CLUTCH | 1 | |
| 3T2397 | 31 PLATE (EXTERNAL TEETH) | 7 | |
| 3T2398 | 32 PLATE (INTERNAL TEETH) | 6 | |
| 3T2399 | 33 PLATE-CLUTCH | 1 | |
| 4F8824 | 34 SEAL-O-RING | 1 | |
| 7T8746 | 35 RING-LATHE CUT | 1 | |
| 8B7789 | 36 RING-SNAP | 1 | |
| 3T2427 | 37 SPRING | 1 | |
| 3T2405 | 38 RING-SNAP | 1 | |
| 3T2403 | 39 RETAINER-SPRING | 1 | |
| 6V4355 | 40 RACE-THRUST BEARING | 1 | |
| 1T1581 | 41 BEARING-THRUST | 2 | |
| 1T1582 | 42 RACE-THRUST BEARING | 1 | |
| 1T1583 | 43 RACE-THRUST BEARING | 2 | |
| 7E1137 | 44 SHAFT AS (57-TEETH) | 1 | |
| 2D6642 | 45 BALL | 2 | |
| 9F8125 | LOCKWASHER | 1 | |
| 6F7002 | 46 PIN | 1 | |
| 3N2321 | 47 SCREEN AS-FILTER (MARINE TRANSMISSION) | 1 | |
| 8F0208 | 48 GROMMET | 1 | |
| 3T2432 | 49 TUBE-SUCTION | 1 | |
| 8L2779 | 50 SEAL-O-RING | 4 | |
| 3T2404 | 51 RETAINER-BEARING | 1 | |
| 3T2419 | 52 SHIM (.13MM THK) | 3 | |
| 3T2420 | SHIM (.18MM THK) | 3 | |
| 3T2421 | SHIM (.50MM THK) | 3 | |
| 4B4158 | 53 SCREW-DRIVE (NO 4X0.25-IN) | 2 | |
| 3T2412 | 54 SHIELD-RETAINER | 1 | |
| 5K2595 | 55 SEAL-LIP TYPE | 1 | |
| 7E1136 | 56 SHAFT-INPUT (54-TEETH) | 1 | |
| 6V9506 | 57 SEAL-LIP TYPE | 1 | |
| 5P9652 | 58 CUP-BEARING | 1 | |
| 5P9651 | CONE-BEARING | 1 | |
| 6V3822 | 59 BOLT (M10X1.5X35-MM) | 8 | |
| 3T2428 | 60 SUPPORT-BEARING | 1 | |
| 3T2413 | 61 SHIM (.13MM THK) | 3 | |
| 3T2414 | SHIM (.18MM THK) | 3 | |
| 3T2415 | SHIM (.51MM THK) | 3 | |
| 6V4248 | 62 BOLT (M10X1.5X25-MM) | 16 | |
| 3T2382 | 63 ADAPTER | 1 | |
| 6S6031 | 64 CUP-BEARING | 1 | |
| 6S6032 | CONE-BEARING | 1 | |
| 3T2410 | 65 SHIELD-OIL | 1 | |
| 1T1585 | 66 CUP-BEARING | 1 | |
| 1T1584 | CONE-BEARING | 1 | |
| 7T6163 | 67 SHIELD-RETAINER | 1 | |
| 2H4337 | 68 SCREW-DRIVE (NO 10X0.5-IN) | 5 | |
| 7T1445 | 69 GEAR-OUTPUT (68-TEETH) | 1 | |
| 7L2224 | 70 SEAL-O-RING | 1 | |
| 9S4190 | 71 PLUG-O-RING (7/8-14-THD) | 1 | |
| 2A4576 | 72 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 6V0957 | CONE-BEARING | 1 | |
| 3T2385 | 73 FLANGE-OUTPUT | 1 | |
| 7L2188 | 74 SEAL-RUBBER | 1 | |
| 3T2434 | 75 WASHER-RETAINING | 1 | |
| 1D4627 | 76 BOLT (7/8-9X3-IN) | 1 | |
| 3T2409 | 77 SHAFT-OUTPUT (24 TEETH) | 1 | |
| 5N5262 | 78 SHIM (.127MM THK) | 2 | |
| 5N5264 | SHIM (.508MM THK) | 2 | |
| 3T2384 | 79 DIVIDER-OIL | 1 | |
| 6S6031 | 80 CUP-BEARING | 1 | |
| 6S6032 | CONE-BEARING | 1 | |
| 3T2427 | 81 SPRING | 1 | |
| 7T8746 | 82 RING-LATHE CUT | 1 | |
| 3T2400 | 83 PLATE | 1 | |
| 4B4158 | SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 4F8824 | 84 SEAL-O-RING | 1 | |
| 3T2399 | 85 PLATE-CLUTCH | 1 | |
| 3T2397 | 86 PLATE (EXTERNAL TEETH) | 7 | |
| 3T2398 | PLATE (INTERNAL TEETH) | 6 | |
| 8B7789 | 87 RING-SNAP | 1 | |
| 3T2405 | 88 RING-SNAP | 1 | |
| 6V4355 | 89 RACE-THRUST BEARING | 1 | |
| 1T1583 | 90 RACE-THRUST BEARING | 2 | |
| 3T2403 | 91 RETAINER-SPRING | 1 | |
| 1T1581 | 92 BEARING-THRUST | 2 | |
| 1T1582 | 93 RACE-THRUST BEARING | 1 | |
| 3D9126 | 94 CUP | 1 | |
| 3D9125 | CONE-BEARING | 1 | |
| 3T2425 | 95 SPACER-BEARING | 1 | |
| 3T2422 | 96 SHIM (0.13-MM THK) | 3 | |
| 3T2423 | SHIM (0.18-MM THK) | 3 | |
| 3T2424 | SHIM (0.5-MM THK) | 3 | |
| 6L9736 | 97 RING-PISTON | 2 | |
| 7E1138 | 98 SHAFT AS (57-TEETH) | 1 | |
| 2D6642 | 99 BALL | 2 | |
| 9F8125 | LOCKWASHER | 1 | |
| 6F7002 | 100 PIN | 1 | |
| 7T1444 | 101 PINION AS | 1 | |
| 3T2396 | 102 PISTON-CLUTCH | 1 | |
| 9Y5810 | 103 CLOSURE | 1 |
