System And Components
118-1102 LINES GP-STEERINGS/N 7SR1451-2267
Group No: 118-1102
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S9703 | 1 TUBE-RETAINER | 2 | |
| 5T6374 | 2 SPACER (11X20X40-MM THK) | 1 | |
| 9R4688 | 3 HOSE AS | 1 | |
| 9T8844 | 4 VALVE-CHECK | 1 | |
| 1198474 | 5 PUMP GP-METERING (HMU) | 1 | |
| 1334824 | 6 HOSE AS | 1 | |
| 1334825 | 7 HOSE AS | 1 | |
| 1334826 | 8 HOSE AS | 2 | |
| 1334827 | 9 HOSE AS | 2 | |
| 1488316 | 10 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488340 | 11 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488341 | 12 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488342 | 13 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488345 | 14 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488358 | 15 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488369 | 16 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8628 | ELBOW | 1 | |
| 1488408 | 17 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1488411 | 18 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1488414 | 19 REDUCER AS | 1 | |
| 6V8943 | REDUCER | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488421 | 20 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T2883 | TEE | 1 | |
| 1488444 | 21 TEE AS-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 3K0360 | 22 SEAL-O-RING | 1 | |
| 5P7464 | 23 CLIP (SLOT) | 6 | |
| 5P7465 | 24 CLIP (TAB) | 6 | |
| 6D3479 | 25 CLIP (LOOP) | 1 | |
| 6D4244 | 26 CLIP (LOOP) | 2 | |
| 6V1249 | 27 GROMMET (22-MM ID) | 6 | |
| 7J9108 | 28 SEAL-O-RING | 1 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4133 | 30 NUT (M10X1.5-THD) | 1 | |
| 8T4172 | 31 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4195 | 32 BOLT (M10X1.5X30-MM) | 1 | |
| 9X8250 | 33 CLIP (LOOP) | 1 |
