System And Components
246-7095 AIR COMPRESSOR GPS/N 9DG3580-UP
Group No: 246-7095
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0992374 | 2 BOLT-SOCKET HEAD (M5X0.8X12-MM) | 2 | |
| 2P4358 | 3 FLANGE | 1 | |
| 3K0360 | 4 SEAL-O-RING | 1 | |
| 6D1004 | 5 GASKET | 1 | |
| 6V1820 | 6 BOLT (M10X1.5X30-MM) | 2 | |
| 6V5221 | 7 BOLT (M8X1.25X80-MM) | 4 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 2 | |
| 8T0267 | 9 BOLT-SOCKET HEAD (M6X1X12-MM) (M6X1X12-MM) | 4 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8005 | 11 PLUG (3/4-16-THD) | 1 | |
| 2255222 | VALVE AS-PRESSURE RELIEF (AIR COMPRESSOR) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 2175232 | KIT-GASKET (AIR COMPRESSOR) | 1 | |
| 2175237 | KIT-UNLOADER (AIR COMPRESSOR) | 1 | |
| 2175240 | KIT-SEAL (AIR COMPRESSOR) | 1 |
