System And Components
246-7095 AIR COMPRESSOR GPPROVIDES A 11 TOOTH REAR DRIVE SPLINE AND REAR MOUNTED FLANGE BOLT PATTERN ROTATED TO PROVIDE CLEARANCE FOR A HYD PUMP
Group No: 246-7095
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0992374 | 1 BOLT-SOCKET HEAD (M5X0.8X12-MM) | 2 | |
| 2P4358 | 2 FLANGE | 1 | |
| 6D1004 | 3 GASKET | 1 | |
| 6V1820 | 4 BOLT (M10X1.5X30-MM) | 2 | |
| 6V5221 | 5 BOLT (M8X1.25X80-MM) | 4 | |
| 6V5839 | 6 WASHER (11X21X2.5-MM THK) | 2 | |
| 8T0267 | 7 BOLT-SOCKET HEAD (M6X1X12-MM) (M6X1X12-MM) | 4 | |
| 9M1974 | 8 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2255222 | VALVE AS-PRESSURE RELIEF | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 3290222 | KIT-HEAD (AIR COMPRESSOR) | 1 | |
| 2175232 | KIT-GASKET (AIR COMPRESSOR) | 1 | |
| 3356328 | KIT-UNLOADER (AIR COMPRESSOR) | 1 | |
| 2606821 | KIT-SEAL | 1 |
