System And Components
163-3120 VALVE GP-PILOT -JOYSTICK, 3-FUNCTIONS/N 7ZM440-UP; 9WM1013-UP
Group No: 163-3120
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1837263 | 1 PLUG AS | 12 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1488407 | 2 PLUG AS | 2 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8636 | 3 CONNECTOR | 1 | |
| 1411095 | 4 ADAPTER | 2 | |
| 1414852 | 5 BOOT | 1 | |
| 1417481 | 6 SPACER | 1 | |
| 1419236 | 7 SCREEN AS (PILOT OIL) | 1 | |
| 1468477 | 8 BRACKET | 1 | |
| 1468478 | 9 CUP | 1 | |
| 1468981 | 10 PIN | 1 | |
| 1634636 | 11 PLATE GP-PILOT VALVE (AUXILIARY) | 1 | |
| 2022564 | 12 PIVOT GP-PILOT VALVE (AUXILIARY) | 1 | |
| 0339139 | 13 RING-RETAINING | 2 | |
| 1028806 | 14 KIT-RECEPTACLE (8-PIN) | 1 | |
| 1053481 | 15 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 1 | |
| 1369292 | 16 BOOT | 1 | |
| 1409926 | 17 BOLT-SOCKET HEAD (M6X1X150-MM) | 2 | |
| 1473322 | 18 PLATE GP-PILOT VALVE (JOYSTICK) | 1 | |
| 1538947 | 19 SWIVEL AS | 1 | |
| 1633107 | 20 VALVE GP-PILOT CARTRIDGE (RAISE) | 1 | |
| 1633108 | 21 VALVE GP-PILOT CARTRIDGE (RACK BACK) | 1 | |
| 1633109 | 22 VALVE GP-PILOT CARTRIDGE (LOWER) | 1 | |
| 1945033 | 23 VALVE GP-PILOT CARTRIDGE (DUMP) | 1 | |
| 1633111 | 24 VALVE GP-PILOT CARTRIDGE (AUXILIARY) | 2 | |
| 6V8397 | 25 SEAL-O-RING | 5 | |
| 3J1907 | 26 SEAL-O-RING | 1 | |
| 5C2890 | 28 NUT (M6X1-THD) | 2 |
