System And Components
269-5308 AIR COMPRESSOR GPFOR USE WITH LINES GP-AIR COMPRESSOR
Group No: 269-5308
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1M3381 | 1 SPACER (0.438X0.75X1-IN THK) | 1 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 1 | |
| 2233505 | 3 SEAL | 1 | |
| 2255222 | 4 VALVE AS-PRESSURE RELIEF (AIR COMPRESSOR) | 1 | |
| 2M9780 | 4A SEAL-O-RING | 1 | |
| 2683297 | 5 BRACKET | 1 | |
| 2705094 | 6 HOSE AS | 1 | |
| 2705098 | 7 HOSE AS | 1 | |
| 2705099 | 8 TUBE AS | 1 | |
| 2860473 | 9 AIR COMPRESSOR GP | 1 | |
| 0054173 | 10 ELBOW | 1 | |
| 0307946 | 11 ELBOW | 1 | |
| 1184728 | 12 ELBOW | 1 | |
| 1B3057 | 13 CLIP | 1 | |
| 3E4353 | 14 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 4K8864 | 15 CLIP (LOOP) | 1 | |
| 5P7970 | 16 NUT (M8X1.25-THD) | 2 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6V3250 | 18 SEAL-O-RING | 1 | |
| 6V3251 | 19 SEAL-O-RING | 1 | |
| 6V4248 | 20 BOLT (M10X1.5X25-MM) | 2 | |
| 6V5048 | 21 SEAL-O-RING | 1 | |
| 6V5839 | 22 WASHER (11X21X2.5-MM THK) | 3 | |
| 6V5842 | 23 BOLT (M10X1.5X40-MM) | 1 | |
| 6V6317 | 24 BOLT (M10X1.5X20-MM) | 2 | |
| 6V6609 | 25 SEAL-O-RING | 3 | |
| 6V7611 | 26 BOLT (M12X1.75X40-MM) | 3 | |
| 7B1598 | 27 CLIP | 1 | |
| 8M0505 | 28 ADAPTER | 2 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S4191 | 30 PLUG (9/16-18-THD) | 1 |
