System And Components
359-6795 HINGE & MOTOR GP-LADDERS/N AMA1-UP
Group No: 359-6795
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4483 | 1 PLUG | 1 | |
| 1100012 | 2 CONE-BEARING | 2 | |
| 1100013 | 3 CUP-BEARING | 2 | |
| 2589912 | 4 BEARING-THRUST | 2 | |
| 2589915 | 5 BUSHING | 2 | |
| 2590138 | 6 SHAFT | 1 | |
| 2590141 | 7 COUPLING-HOUSING | 1 | |
| 2590142 | 8 COUPLING | 1 | |
| 2590342 | 9 SUPPORT AS | 1 | |
| 2763684 | 10 SHAFT | 1 | |
| 2763685 | 11 GEAR (35-TEETH) | 1 | |
| 2763686 | 12 SHIM PACK (INCLUDES 4-SHIMS) | 1 | |
| 2763687 | 13 SHIM PACK (INCLUDES 4-SHIMS) | 4 | |
| 2763688 | 14 GASKET | 1 | |
| 2763689 | 15 GASKET | 1 | |
| 2779792 | 16 SEAL-LIP TYPE | 2 | |
| 2795447 | 17 CAP | 2 | |
| 2795448 | 18 COUPLING | 2 | |
| 2810111 | 19 SEAL | 2 | |
| 2875812 | 20 SEAL-O-RING | 2 | |
| 3242564 | 21 PLATE AS | 1 | |
| 3402114 | 22 MOTOR GP-GEROTOR | 1 | |
| 3633193 | 23 KIT-HOUSING | 1 | |
| 1H5728 | 24 SEAL-O-RING | 1 | |
| 3E8007 | 25 BOLT-SOCKET HEAD (M12X1.75X90-MM) | 2 | |
| 3K8282 | 26 PIN-SPRING | 1 | |
| 7J0204 | 27 SEAL-O-RING | 3 | |
| 7M8485 | 28 SEAL-O-RING | 1 | |
| 7X3392 | 29 WASHER-HARD (13.5X22.5X3-MM THK) | 2 | |
| 8C8451 | 30 BOLT (M6X1X40-MM) | 12 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4195 | 32 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4196 | 33 BOLT (M10X1.5X35-MM) | 12 | |
| 9S8007 | 34 PLUG (3/8-24-THD) | 3 | |
| 9X8256 | 35 WASHER (6.6X12X2-MM THK) | 12 |
