System And Components
222-8242 CYLINDER BLOCK GPS/N MAE1-UP; 7JK1-UP
Group No: 222-8242 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2175416 | 1 CYLINDER BLOCK GP | 1 | |
| 2128567 | 2 EYE | 1 | |
| 5I7603 | 3 EYE | 1 | |
| 8T4179 | 4 BOLT (M12X1.75X20-MM) | 2 | |
| 0962501 | 5 LOCKWASHER | 2 | |
| 5I7588 | 6 SET-BEARING (STANDARD) | 7 | |
| 5I7784 | SET-BEARING (0.25-MM US) | 7 | |
| 5I7785 | SET-BEARING (0.5-MM US) | 7 | |
| 5I7786 | SET-BEARING (0.75-MM US) | 7 | |
| 5I7654 | 7 PLATE (STANDARD) | 3 | |
| 5I7787 | PLATE (0.15-MM OS) | 3 | |
| 5I7788 | PLATE (0.3-MM OS) | 3 | |
| 5I7789 | PLATE (0.45-MM OS) | 3 | |
| 2666210 | 8 SWITCH-PRESSURE (OIL PRESSURE) | 1 | |
| 4D7794 | 9 CLIP | 1 | |
| 5I7978 | 10 SLEEVE | 1 | |
| 7X2536 | 11 BOLT (M8X1.25X14-MM) | 1 | |
| 3B4505 | 12 LOCKWASHER | 1 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 2 | |
| 7X0796 | 14 LOCKWASHER (10.2X18.4X2.5-MM THK) | 2 |
