482-0872 BUCKET GP-DITCH CLEANINGS/N DZF1-UP
Group No: 482-0872 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 4959816 | 2 COVER-CYLINDER (LH) | 1 | |
| 4663085 | 3 PIVOT AS | 1 | |
| 9R2821 | 3A BOSS (M10X1.5X15-MM) | 7 | |
| 4829099 | 3B BUSHING | 2 | |
| 1598035 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 5 FILM-WARNING (READ OMM) | 1 | |
| 4638184 | 6 COVER-CYLINDER (RH) | 2 | |
| 4663099 | 7 SPACER (35X90X6-MM THK) | 1 | |
| 4699342 | 8 CYLINDER GP-BUCKET (LH)(LH) | 1 | |
| 4699353 | 9 CYLINDER GP-BUCKET (RH)(RH) | 1 | |
| 4976328 | 12 LINES GP-GREASE | 1 | |
| 4976330 | 13 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 4982871 | 14 PIN AS | 1 | |
| 4982872 | 15 PIN AS | 2 | |
| 4982873 | 16 PIN AS | 1 | |
| 7X2621 | 17 BOLT (M10X1.5X12-MM) | 3 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4222 | 20 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 8T4779 | 21 BOLT (M16X2X35-MM) | 2 | |
| 4820892 | 22 BUCKET AS-DITCH CLEANING | 1 | |
| 4421826 | 23 PLATE-WEAR | 2 | |
| 4428279 | 24 EDGE | 1 | |
| 4494612 | 25 PLATE-WEAR | 1 | |
| 4663078 | 26 PLATE AS-HINGE | 1 | |
| 2C9259 | 27 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4428290 | 28 PLATE (CORNER) | 2 | |
| 4827577 | 29 GUSSET (LH) | 1 | |
| 4827578 | 30 GUSSET (RH) | 1 | |
| 1102961 | 31 BOSS (M6X1.0X16-MM) | 2 | |
| 9R2821 | 32 BOSS (M10X1.5X15-MM) | 4 |
