System And Components
484-0199 BUCKET GP-DITCH CLEANINGS/N TFX1-UP
Group No: 484-0199 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 4854862 | 2 PIVOT AS | 1 | |
| 4845091 | 2A BUSHING | 2 | |
| 9R2821 | 2B BOSS (M10X1.5X15-MM) | 5 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1598035 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 5 FILM-WARNING (READ OMM) | 1 | |
| 4988995 | 7 PIN AS | 1 | |
| 4988996 | 8 PIN AS | 2 | |
| 4988997 | 9 PIN GP-BUCKET | 1 | |
| 4842102 | 10 CYLINDER GP-BUCKET (LH) | 1 | |
| 4842103 | 11 CYLINDER GP-BUCKET (RH) | 1 | |
| 4848127 | 12 SPACER (35X90X3-MM THK) | 1 | |
| 4978492 | 14 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 7X2621 | 15 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4222 | 16 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4779 | 17 BOLT (M16X2X35-MM) | 2 | |
| 4762387 | 18 BUCKET AS-DITCH CLEANING | 1 | |
| 4827577 | 19 GUSSET (LH) | 1 | |
| 4827578 | 20 GUSSET (RH) | 1 | |
| 4859710 | 21 EDGE | 1 | |
| 4902816 | 22 EDGE-BASE | 1 | |
| 4904934 | 23 PLATE AS-HINGE | 1 | |
| 9R2821 | 24 BOSS (M10X1.5X15-MM) | 4 | |
| 2C9259 | 25 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4421795 | 26 PLATE (CORNER) | 2 |
